Datasheet for part number MS3106E16S1P
Our Catalog Part Number: MS3106E16S1P
Our Global Manufacturing Part Number: 024269-0001
Brand: Cannon Product Category: Circular Product Line: MIL-DTL 5015 Series I Series: MIL-C-5015
Product Datasheet
Thread Connector with threaded coupling
Shell Style Plug, straight
Endbell Style Endbell with clamp and bushing
Gender Pin
Shell Size 16S
Contact Arrangement 16S-1
Number of contacts 7 contacts size 16S
Contact Type Solder Cup
Contact Plating Hard silver
Contacts installed yes
Shielding no
Contact Rating at +20 °C (68 °F)
(Size 15/15S/16/16S)
22 A
Contact Resistance
(Size 15/15S/16/16S)
6 mΩ
Operating Voltage
In case of voltages greater than 50V the connector
must be used in accordance with DIN VDE part 410,
IEC 60364-4-41.
Insulator Resistance
Acc. To VG95319, part 2, test no. 5.12
and VG95210, part 32, test conditions B,
standard insulator material > 1000 MΩ
Test Voltage 1600 Vrms
Air and Creepage Paths (Min) 1,1 mm
Ambient Temperature
Standard insulator material -55°/+125°C
(-67/257°F)
Safety Provisions IP65 acc. to DIN 40 050
Salt Spray Resistance 500 hours salt spray resistant
Mating Cycles 500 min
Sep. Force per Contact
(Size 15/15S/16/16S)
1,0 N
Gage
For infos on Gage please see catalog
VG95234, part 1
Coupling Torque Closing: 5,5 Nm max / Opening: 0,46 Nm min
Contact Retention
(Size 15/15S/16/16S)
35 N
Shell Material Aluminium alloy
Shell Plating Olive drab chromate coating over cadmium plating
Insulator and Gromet Material Neoprene
Contact Material Copper alloy
Harnessing Info: Contact Cross-Section See assembly instruction
Harnessing Info: Insulator Diameter See assembly instruction
Wire Stripping
(Size 15/15S/16/16S)
6,2 mm
General Info
All tests in accordance with VG95319 and/or if
applicable with VG95210
Specifications and dimensions subject to change.
Page 1 of
1
