MSP430F20x3
MSP430F20x2
MSP430F20x1
www.ti.com
SLAS491I –AUGUST 2005–REVISED DECEMBER 2012
MIXED SIGNAL MICROCONTROLLER
1
FEATURES
• Low Supply Voltage Range 1.8 V to 3.6 V • Serial Onboard Programming, No External
Programming Voltage Needed, Programmable
• Ultra-Low Power Consumption
Code Protection by Security Fuse
– Active Mode: 220 µA at 1 MHz, 2.2 V
• On-Chip Emulation Logic With Spy-Bi-Wire
– Standby Mode: 0.5 µA
Interface
– Off Mode (RAM Retention): 0.1 µA
• Family Members:
• Five Power-Saving Modes
– MSP430F2001
• Ultra-Fast Wake-Up From Standby Mode in
– 1KB + 256B Flash Memory
Less Than 1 µs
– 128B RAM
• 16-Bit RISC Architecture, 62.5-ns Instruction
– MSP430F2011
Cycle Time
– 2KB + 256B Flash Memory
• Basic Clock Module Configurations:
– 128B RAM
– Internal Frequencies up to 16 MHz With
Four Calibrated Frequencies to ±1% – MSP430F2002
– Internal Very Low-Power Low-Frequency – 1KB + 256B Flash Memory
Oscillator
– 128B RAM
– 32-kHz Crystal
– MSP430F2012
– External Digital Clock Source
– 2KB + 256B Flash Memory
• 16-Bit Timer_A With Two Capture/Compare
– 128B RAM
Registers
– MSP430F2003
• On-Chip Comparator for Analog Signal
– 1KB + 256B Flash Memory
Compare Function or Slope A/D
– 128B RAM
(MSP430F20x1)
– MSP430F2013
• 10-Bit 200-ksps A/D Converter With Internal
– 2KB + 256B Flash Memory
Reference, Sample-and-Hold, and Autoscan
(MSP430F20x2) – 128B RAM
• 16-Bit Sigma-Delta A/D Converter With • Available in 14-Pin Plastic Small-Outline Thin
Differential PGA Inputs and Internal Reference Package (TSSOP), 14-Pin Plastic Dual Inline
(MSP430F20x3) Package (PDIP), and 16-Pin QFN
• Universal Serial Interface (USI) Supporting SPI • For Complete Module Descriptions, See the
and I2C (MSP430F20x2 and MSP430F20x3) MSP430x2xx Family User's Guide (SLAU144)
• Brownout Detector
DESCRIPTION
The Texas Instruments MSP430 family of ultra-low-power microcontrollers consist of several devices featuring
different sets of peripherals targeted for various applications. The architecture, combined with five low-power
modes is optimized to achieve extended battery life in portable measurement applications. The device features a
powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute to maximum code efficiency.
The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less than 1 µs.
The MSP430F20xx series is an ultra-low-power mixed signal microcontroller with a built-in 16-bit timer and ten
I/O pins. In addition, the MSP430F20x1 has a versatile analog comparator. The MSP430F20x2 and
MSP430F20x3 have built-in communication capability using synchronous protocols (SPI or I2C) and a 10-bit A/D
converter (MSP430F20x2) or a 16-bit sigma-delta A/D converter (MSP430F20x3).
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
PRODUCTION DATA information is current as of publication date.
Copyright © 2005–2012, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
