RATING AND CHARACTERISTIC CURVES ( MURS120 )
FIG.1 - REVERSE RECOVERY TIME CHARACTERISTIC AND TEST CIRCUIT DIAGRAM
+
NOTES : 1. Rise Time = 7 ns max., Input Impedance = 1 megaohm, 22 pF.
2. Rise Time = 10 ns max., Source Impedance = 50 ohms.
3. All Resistors = Non-inductive Types.
FIG.2 - DERATING CURVE FOR OUTPUT FIG.3 - MAXIMUM NON-REPETITIVE PEAK
RECTIFIED CURRENT FORWARD SURGE CURRENT
60 80 100 120 140 160 180 200 1 2 4 6 10 20 40 60 100
LEAD TEMPERATURE, ( °C)
NUMBER OF CYCLES AT 60Hz
FIG.4 - TYPICAL FORWARD CHARACTERISTICS FIG.5 - TYPICAL REVERSE CHARACTERISTICS
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6
Page 2 of 2 Rev. 03 : September 28, 2012
TJ = 25 °C
0.8
0.6
0.4
0.2
1.0
10
10
1.0
40
0
50
0
30
20
10
1.0
0.1
0.1
PEAK FORWARD SURGE
CURRENT, AMPERES
AVERAGE FORWARD OUTPUT
CURRENT, AMPERES
80
0.01
100 1400 20 40 60 120
PERCENT OF RATED REVERSE
VOLTAGE, (%)
REVERSE CURRENT, MICROAMPERES
TJ = 25 °C
TJ = 100 °C
FORWARD VOLTAGE, VOLTS
FORWARD CURRENT, AMPERES
0.01
SET TIME BASE FOR 15 ns/cm
1cm
Trr
+ 0.5 A
0
- 0.25 A
- 1.0 A
OSCILLOSCOPE
( NOTE 1 )
1 Ω
50 Ω 10 Ω
D.U.T.
50 Vdc
(approx
.)
PULSE
GENERATOR
( NOTE 2 )
IATF 0113686
