Micron Serial NOR Flash Memory
3V
, Multiple I/O, 4KB Sector Erase
N25Q032A
Features
• SPI-compatible serial bus interface
• 108 MHz (MAX) clock frequency
• 2.7–3.6V single supply voltage
• Dual/quad I/O instruction provides increased
thr
oughput up to 432 MHz
• Supported protocols
– Extended SPI, dual I/O, and quad I/O
• Execute-in-place (XIP) mode for all three protocols
– Configurable via volatile or nonvolatile registers
– Enables memory to work in XIP mode directly af-
ter power-on
• PROGRAM/ERASE SUSPEND operations
• Continuous read of entire memory via a single com-
mand
– FAST READ
– QUAD or DUAL OUTPUT FAST READ
– QUAD or DUAL I/O FAST READ
• Flexible to fit application
– Configurable number of dummy cycles
– Configurable output buffer
– RESET function available upon customer request
• 64-byte, user-lockable, one-time programmable
(OTP) dedicated area
• Erase capability
– Subsector erase 4KB uniform granularity blocks
– Sector erase 64KB uniform granularity blocks
– Full-chip erase
• Write protection
– Software write protection applicable to every
64KB sector via volatile lock bit
– Hardware write protection: protected area size
defined by four nonvolatile bits (BP0, BP1, BP2,
and TB)
– Additional smart protections, available upon re-
quest
• Electronic signature
– JEDEC-standard, 2-byte signature (BA16h)
– Unique ID code: 17 read-only bytes, including:
• Two additional extended device ID bytes to
identify device factory options
• Customized factory data (14 bytes)
• Minimum 100,000 ERASE cycles per sector
• More than 20 years data retention
• Packages (JEDEC-standard, RoHS compliant)
– F4 = U-PDFN-8 4mm x 3mm (MLP8)
– F6 = V-PDFN-8 6mm x 5mm (MLP8)
– F8 = V-PDFN-8 8mm x 6mm (MLP8)
– 12 = T-PBGA-24b05 6mm x 8mm
– SC = SOP2-8 150 mils body width (SO8N)
– SF = SOP2-16 300 mils body width (SO16W)
– SE = SOP2-8 208 mils body width (SO8W)
32Mb, 3V, Multiple I/O Serial Flash Memory
Featur
es
PDF: 09005aef84566622
n25q_32mb_3v_65nm.pdf - Rev
. J 2/15 EN
1
Micron Technology, Inc. reserves the right to change products or specifications without notice.
© 2011 Micron Technology, Inc. All rights reserved.
Products and specifications discussed herein are subject to change by Micron without notice.
