Informational Notice (IN)
Page 1 of 2
IN no.: IN_127 rev. 1.0
Date:
2020-02-11
Device affected: All
Device version / Build Code: All
Data sheet references:
N/A
Agreement reference:
N/A
Customers reference:
N/A
Description of change:
Outer box label revision. Please see below details of change
Items changed
CURRENT
TO
1) Sales order no.
Sales order no. (1k)
Sales order no. (14K) = Sales Order No.+Sales
order line no.+Delivery line no.
2) Shipment ID
None
Will occupy the previous Delivery No. field and
will use data identifier 2K.
3) Delivery no.
Appears as 4
th
row and uses 2K as data
identifier
Will be moved to the last row and will replace
the trace code info. Will use data identifier 9K.
The trace codes will only show on the inner
box labels.
4) 2D barcode
1PPart number|KCustomer PO No.|
1KNordic Sales order no.| 2KDelivery
No.|QQuantity|4LCountry of Origin
|13QCarton no/total no. of cartons
1PPart number|KCustomer PO No.|14KNordic
Sales order no.+SO line no.+Delivery line no.
|2KShipment ID|QQuantity| 4LCountry of
Origin |13QCarton no/total no. of cartons
Note: If more than one Sales order line no. and/or delivery line no. is combined in an outer box, the respective field will show
“mixed”.
During an initial transition phase, the label format will change as outlined above, however, the newly-introduced fields (Sales
Order line no., delivery line no. and Shipment ID) will be left blank.
Impact: Does the change affect product:
1. Form No Yes – describe:
2. Fit No Yes – describe:
3. Function No Yes – describe:
4. Quality or Reliability No Yes – describe:
Classification of change Minor Major
Reason for change:
Improve logistical traceability
Consequences of change:
Please take note of new and altered label fields. Customers using the 2D barcode of the outer box label should review their 2D
barcode parsing configuration.
Verification of change:
The changes have been qualified according to Nordic Semiconductor’s standard quality procedures.
