若手册格式错乱，请下载阅览PDF原文件
Low-Cost, Low-Power, Rail-to-Rail
OPERATIONAL AMPLIFIERS
MicroAmplifier
™
Series
FEATURES
● LOW QUIESCENT CURRENT: 150µA typ
● RAIL-TO-RAIL INPUT
● RAIL-TO-RAIL OUTPUT (within 1mV)
● SINGLE SUPPLY CAPABILITY
● LOW COST
●
Micro
SIZE PACKAGE OPTIONS:
SOT23-5
MSOP-8
TSSOP-14
● BANDWIDTH: 1MHz
● SLEW RATE: 1V/µs
● THD + NOISE: 0.006%
APPLICATIONS
● COMMUNICATIONS
● PCMCIA CARDS
● DATA ACQUISITION
● PROCESS CONTROL
● AUDIO PROCESSING
● ACTIVE FILTERS
● TEST EQUIPMENT
● CONSUMER ELECTRONICS
DESCRIPTION
The OPA342 series rail-to-rail CMOS operational
amplifiers are designed for low-cost, low-power, min-
iature applications. They are optimized to operate on
a single supply as low as 2.5V with an input common-
mode voltage range that extends 300mV beyond the
supplies.
Rail-to-rail input/output and high-speed operation make
them ideal for driving sampling Analog-to-Digital Con-
verters (ADC). They are also well suited for general-
purpose and audio applications and providing I/V con-
version at the output of Digital-to-Analog Converters
(DAC). Single, dual, and quad versions have identical
specs for design flexibility.
The OPA342 series offers excellent dynamic response
with a quiescent current of only 250µA max. Dual and
quad designs feature completely independent circuitry
for lowest crosstalk and freedom from interaction.
OPA342
OPA2342
OPA4342
®
OPA342
O
P
A
3
4
2
O
P
A
2
3
4
2
O
P
A
43
42
OPA4342
SINGLE DUAL QUAD
PACKAGE OPA342 OPA2342 OPA4342
SOT23-5 ✔
MSOP-8 ✔
SO-8 ✔✔
TSSOP-14 ✔
SO-14 ✔
DIP-14 ✔
SPICE MODEL available at www.burr-brown.com.
Copyright © 2000, Texas Instruments Incorporated SBOS106A Printed in U.S.A. August, 2000
