Optically Coupled Isolator
OPI110, OPI1264 Series
© TT electronics plc
Issue B 11/2016 Page 1
TT Electronics | OPTEK Technology
1645 Wallace Drive, Carrollton, TX 75006|Ph: +1 972 323 2200
www.electronics.com | sensors@electronics.com
General Note
TT Electronics reserves the right to make changes in product specicaon without
noce or liability. All informaon is subject to TT Electronics’ own data and is
considered accurate at me of going to print.
Descripon:
Each Optoisolator in this data sheet contains an infrared Light Eming Diode (LED) and a NPN silicon Photosensor. The
OPI110 and OPI1264 devices have 890 nm Light Eming Diode (LED) and NPN phototransistor sensor. The devices are
sealed in a precast opaque housing with a opcally transmissive path between the LED and the photosensor.
The Optoisolators in this data sheet are UL approved under E58730.
This series is designed for transmission of informaon between one power supply voltage and another where the potenals
during surge condions are not greater than the guaranteed isolaon voltage.
Custom electrical, wire and cabling and connectors are available. Contact your local representave or OPTEK for more
informaon.
Applicaons:
High voltage isolaon between input and output
Electrical isolaon in dirty environments
Industrial equipment
Medical equipment
Features:
15 kV electrical isolaon
Choice of phototransistor
Low-cost plasc housing
UL recognized File No. E58730
Ordering Information
Part
Number
LED
Peak
Wavelength
Sensor
Isolation
Voltage
(,000)
CTR
Min /
Max
I
F
(mA)
Typ / Max
V
CE
(Volts)
Max
Lead
Length /
Spacing
OPI110
890 nm
Transistor
10
12.5 / NA
10 / 40
30 0.50" / 0.55"
OPI110A
25 / NA
OPI110B
50 / 125
OPI110C
100 / NA
OPI1264
Transistor
12.5 / NA
10 / 40
OPI1264A
25 / NA
OPI1264B
50 / 125
OPI1264C
100 / NA
