B0300SB
Revision：12-Jan-17 www.brightking.com
Thyristor Surge Suppressors (TSS) Data Sheet
Description
DO-214AA Thyristor solid state protection thyristor protect
telecommunications equipment such as modems, line cards,
fax machines, and other CPE.
B Series devices are used to enable equipment to meet
various regulatory requirements including GR 1089, ITU
K.20, K.21 and K.45, IEC 60950, UL 60950, and TIA-968
(formerly known as FCC Part 68).
Features
Compared to surge suppression using other technologies, B Series devices offer absolute surge protection
regardless of the surge current available and the rate of applied voltage (dv/dt). B Series devices:
■ Cannot be damaged by voltage
■ Eliminate hysteresis and heat dissipation typically found with clamping devices
■ Eliminate voltage overshoot caused by fast-rising transients
■ Are non-degenerative
■ Will not fatigue
■ Have low capacitance, making them ideal for high-speed transmission equipment
■ Meets MSL level 1, per J-STD-020
Electrical Parameters
Parameter Definition
V
DRM
Peak Off-state Voltage – maximum voltage that can be applied while maintaining off state
V
S
Switching Voltage – maximum voltage prior to switching to on state
V
T
On-state Voltage – maximum voltage measured at rated on-state current
I
DRM
Leakage Current – maximum peak off-state current measured at V
DRM
I
S
Switching Current – maximum current required to switch to on state
I
T
On-state Current – maximum rated continuous on-state current
I
H
Holding Current – typical current required to maintain on state
C
O
Off-state Capacitance – typical capacitance measured in off state
I
PP
Peak Pulse Current – maximum rated peak impulse current
