SIDACtor Device
http://www.littelfuse.com 2 - 28 © 2004 Littelfuse, Inc.
+1 972-580-7777 SIDACtor
®
Data Book and Design Guide
SIDACtor Device
The modified TO-220 Type 61 SIDACtor solid state protection device can be used in
telecommunication protection applications that do not reference earth ground.
SIDACtor devices are used to enable equipment to meet various regulatory requirements
including GR 1089, ITU K.20, K.21 and K.45, IEC 60950, UL 60950, and TIA-968-A
(formerly known as FCC Part 68).
* For surge ratings, see table below.
General Notes:
• All measurements are made at an ambient temperature of 25 °C. I
PP
applies to -40 °C through +85 °C temperature range.
• I
PP
is a repetitive surge rating and is guaranteed for the life of the product.
• Listed SIDACtor devices are bi-directional. All electrical parameters and surge ratings apply to forward and reverse polarities.
• V
DRM
is measured at I
DRM.
• V
S
is measured at 100 V/µs.
• Special voltage (V
S
and V
DRM
) and holding current (I
H
) requirements are available upon request.
• Off-state capacitance (C
O
) is measured at 1 MHz with a 2 V bias and is a typical value.
Electrical Parameters
Part
Number *
V
DRM
Volts
V
S
Volts
V
T
Volts
I
DRM
µAmps
I
S
mAmps
I
T
Amps
I
H
mAmps
C
O
pF
P2000AA61 180 220 4 5 800 2.2 150 30
P2200AA61 200 240 4 5 800 2.2 150 30
P2400AA61 220 260 4 5 800 2.2 150 30
P2500AA61 240 290 4 5 800 2.2 150 30
P3000AA61 270 330 4 5 800 2.2 150 30
P3300AA61 300 360 4 5 800 2.2 150 30
Surge Ratings
Series
I
PP
0.2x310 µs
Amps
I
PP
2x10 µs
Amps
I
PP
8x20 µs
Amps
I
PP
10x160 µs
Amps
I
PP
10x560 µs
Amps
I
PP
5x320 µs
Amps
I
PP
10x1000 µs
Amps
I
TSM
60 Hz
Amps
di/dt
Amps/µs
A 20 150 150 90 50 75 45 20 500
