Texas Instruments, Inc. PCN#20150327001
Qualification Results
Data Displayed as: Number of lots / Total sample size / Total failed
Type
Test Name / Condition
Duration
Qual Device: VSP5100PDT
QBS Product/Package:
VSP5100PDT
UHAST
Unbiased HAST 130C/85%RH
96 Hours
2/160/0
-
TC
Temperature Cycle, -65/150C
500 Cycles
2/160/0
3/77/0
SD
Solderability
PB-Free
2/44/0
-
LI
Lead Finish Adhesion
Leads
2/30/0
-
HTOL
High Temperature Life Test,
125C
1000 Hours
-
3/120/0
HAST
Biased HAST 130C/85%RH
96 Hours
-
3/77/0
TC
Temperature Cycle, -65/150C
500 Cycles
-
3/77/0
ESD
ESD-HBM
2000V
-
1/3/0
ESD
ESD-CDM
500V
-
1/3/0
LU
Latch-up
Per JESD78
-
1/6/0
- Preconditioning was performed for Autoclave, Unbiased HAST, THB/Biased HAST, Temperature Cycle, Thermal Shock, and HTSL,
as applicable
- The following are equivalent HTOL options based on an activation energy of 0.7eV : 125C/1k Hours, 140C/480 Hours, 150C/300
Hours, and 155C/240 Hours
- The following are equivalent HTSL options based on an activation energy of 0.7eV : 150C/1k Hours, and 170C/420 Hours
- The following are equivalent Temp Cycle options per JESD47 : -55C/125C/700 Cycles and -65C/150C/500 Cycles
Quality and Environmental data is available at TI's external Web site: http://www.ti.com/
Green/Pb-free Status:
Qualified Pb-Free(SMT) and Green
For questions regarding this notice, e-mails can be sent to the regional contacts shown below
or your local Field Sales Representative.
Location
E-Mail
USA
PCNAmericasContact@list.ti.com
Europe
PCNEuropeContact@list.ti.com
Asia Pacific
PCNAsiaContact@list.ti.com
Japan
PCNJapanContact@list.ti.com
