1. Product profile
1.1 General description
Low capacitance ElectroStatic Discharge (ESD) protection diodes in ultra small SMD
plastic packages designed to protect one signal line from the damage caused by ESD and
other transients.
1.2 Features
1.3 Applications
1.4 Quick reference data
PESD5V0S1BA;PESD5V0S1BB;
PESD5V0S1BL
Low capacitance bidirectional ESD protection diodes
Rev. 04 — 20 August 2009 Product data sheet
Table 1. Product overview
Type number Package
NXP JEITA
PESD5V0S1BA SOD323 SC-76
PESD5V0S1BB SOD523 SC-79
PESD5V0S1BL SOD882 -
n Bidirectional ESD protection of one line n ESD protection > 30 kV
n Max. peak pulse power: P
PP
= 130 W n IEC 61000-4-2, level 4 (ESD)
n Low clamping voltage: V
(CL)R
= 14 V n IEC 61000-4-5 (surge); I
PP
= 12 A
n Ultra low leakage current: I
RM
= 5 nA n Ultra small SMD plastic packages
n Cellular handsets and accessories n Communication systems
n Portable electronics n Audio and video equipment
n Computers and peripherals
Table 2. Quick reference data
Symbol Parameter Conditions Min Typ Max Unit
V
RWM
reverse stand-off voltage - - 5 V
C
d
diode capacitance V
R
= 0 V;
f = 1 MHz
- 3545pF
