PF Series
• SIP SSR
• Ratings to 25A (forced air) @ 480 VAC
• SCR output for heavy industrial loads
• AC or DC control
• Zero-crossing (resistive loads) or random-fire (inductive loads) output
PRODUCT SELECTION
Control Voltage
3-15 VDC
AVAILABLE OPTIONS
OUTPUT SPECIFICATIONS
(1)
Description
Operating Voltage (47-63Hz) [Vrms]
48-660
Transient Overvoltage [Vpk]
1200
Maximum Off-State Leakage Current @ Rated Voltage [mArms]
0.1
Minimum Off-State dv/dt @ Maximum Rated Voltage [V/μsec] (2)
500
Maximum Load Current (Convection Air) [Arms] (3)
10
Maximum Load Current (Forced Air) [Arms] (3)
25
Minimum Load Current [Arms]
0.06
Maximum Surge Current (16.6ms) [Apk]
250
Maximum I²t for fusing (8.3 msec) [A² sec]
25 A25 A 25 A
PF240D25
4-15 VDC
PF480D25
PF380D25
15-32 VDC
PFE480D25
PFE380D25PFE240D25
18-36 VAC
PFE240A25
90-140 VAC
PF240A25
12-280
600
0.1
500
10
25
250
0.06
1.6
Maximum On-State Voltage Drop @ Rated Current [Vpk]
260
48-530
1200
0.1
500
10
25
0.06
250
1.6
260
1.6
260
Minimum Power Factor (with Maximum Load)
0.50.5
0.5
Required for valid part number
For options only and not required for valid part number
Series
Operational Current
25: 25 Amps
Operational Voltage
240: 12-280 VAC
380: 48-530 VAC
480: 48-660 VAC
Control Input Type
D: DC Input
A: AC Input
PF
240
Output Type
Blank: Normally Open
-B: Normally Closed
(PF480D25 only)
-B
D 25
Switching Mode
Blank: Zero Voltge Turn-On
R: Random Turn-On
R
Control Voltage
Blank: 3-15 VDC
(240,D suffix only)
4-15 VDC
(380/480,D suffix only)
90-140 VAC (A suffix only)
E: 15-32 VDC (D suffix only)
18-36 VAC (A suffix only)
E
PF380 PF480PF240
