PIC12F510-E/MS 其他数据使用手册 - Microchip（微芯）
制造商:
Microchip（微芯）
分类:
8位微控制器
封装:
MSOP-8
描述:
PIC12F510 8 位闪存微控制器Microchip 的 PIC12 微控制器 (MCU) 是世界首个 8 引脚微控制器。 最初已经作为一次可编程 (OTP) 部件推出，此系列设备继续扩展为额外功能且添加了附加改进功能。 PIC12F510 系列微控制器基于 Microchip 的基线内核，带 2 层深硬件堆栈和 33 个指令。 这些 MCU 提供高达 2 MIPS、高达 1.5 K 字节程序内存和高达 38 字节 SRAM 数据内存。 板载可配置 RC 振荡器，精确度为 ±1%。### 特点33 个指令 2 级硬件堆栈 4 或 8 MHz 可选内部振荡器 6 个输入/输出引脚 一个比较器 一个 8 位计时器 4 通道 8 位模拟到数字转换器 (ADC) 在线串行编程 (ICSP) 在线调试 (ICD) ### PIC12F 微控制器### Microchip PIC12F 8 位 PIC® 微控制器Microchip 的 PIC12F 微控制器 (MCU) 是世界首个 8 引脚微控制器。 最初已经作为一次可编程 (OTP) 部件推出，此系列的设备将继续扩展为 Microchip 添加额外功能，进一步提高规格，并继续提供比以前更大的值。 PIC12F 成功的关键是在一个 8 引脚封装中允许六个输入/输出通道的内部 RC 振荡器。 此 RC 振荡器的更高版本可在 31kHz 和 32MHz 之间配置。展开
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
引脚图在P4P13P15Hot
原理图在P12P14P30P31P32P33P34P35P41P44P48P52
标记信息在P101P102
封装信息在P101P103P104P105P106P107P108P109P115
功能描述在P7
技术参数、封装参数在P58P59P62P68P72P91
应用领域在P7
电气规格在P58P59P62P65P68
