2001 Microchip Technology Inc. DS80061C-page 1
PIC16C773
The PIC16C773 (Rev. B) parts you have received con-
form functionally to the Device Data Sheet
(DS30275A), except for the anomalies described
below.
All of the problems listed here will be addressed in
future revisions of the PIC16C773 silicon.
1. Module: VREF
The VRL low voltage reference does not function
properly. The VRLEN (REFCON<6>) and
VRLOEN (REFCON<4>) bits should be main-
tained cleared.
Work around
None.
Date Codes Pertaining To This Issue:
All.
2. Module: BOR
The Brown-Out Reset module’s selection ranges
have changed. Table 1 shows the new specifica-
tions.
Work around
None.
Date Codes Pertaining To This Issue:
All.
TABLE 1: DC SPECIFICATION CHANGES FROM DATA SHEET
Note: When the manufacture date of a newer ver-
sion of silicon is in production, the last date
where this issue may occur will be specified.
Note: When the manufacture date of a newer ver-
sion of silicon is in production, the last date
where this issue may occur will be specified.
Param
No.
Sym. Characteristic
Tested Specification
Data Sheet
Specification
Units
Min Typ Max Min Typ Max
D005 V
BOR BOR Voltage BORV<1:0> = 0100 2.35 — 2.80 2.5 — 2.66 V
BORV<1:0> = 0101 2.55 — 3.02 2.7 — 2.86 V
BORV<1:0> = 0110 3.95 — 4.71 4.2 — 4.46 V
BORV<1:0> = 0111 4.23 — 5.05 4.5 — 4.78 V
PIC16C773 Rev. B Silicon Errata Sheet
