PIC16(L)F1526/1527
DS80000520E-page 2 2011-2014 Microchip Technology Inc.
TABLE 2: SILICON ISSUE SUMMARY
Module Feature
Item
Number
Issue Summary
Affected
Revisions
(1)
A2 A3 A5
High-Frequency Internal
Oscillator (HFINTOSC)
HFINTOSC Operation 1.1 HFINTOSC is not stable when
VDD < 2.3V.
X
High-Frequency Internal
Oscillator (HFINTOSC)
HFINTOSC Operation 1.2 HFINTOSC Max. VDD at -40°C. X
FVR FVR Ready Bit (FVRRDY) 2.1 FVRRDY bit may not get set at low
VDD and low-operating
temperature.
X
FVR Gain Amplifier 2.2 Higher than expected current
consumption.
XXX
EUSART Break generation – SREN
bit
3.1 Break generation in Asynchronous
mode is inaccurate.
X
EUSART Auto-baud – WUE and
ABDEN bits
3.2 Setting WUE and ABDEN
simultaneously does not perform
auto-baud correctly.
X
Oscillator HFINTOSC Ready/Stable
bit
4.1 Bits remained set to ‘1’ after initial
trigger.
XX
Oscillator Clock Switching 4.2 Clock switching can cause a single
corrupted instruction.
XXX
Oscillator Oscillator Start-up Timer
(OST) bit
4.3 OST bit remains set. X X X
MSSP (Master
Synchronous Serial Port)
SPI Master mode 5.1 Buffer Full (BF) bit or MSSP
Interrupt Flag (SSPIF) bit becomes
set half SCK cycle too early.
XXX
Note 1: Only those issues indicated in the last column apply to the current silicon revision.
