PIC16(L)F1526/1527
DS80000520E-page 4 2011-2014 Microchip Technology Inc.
4. Module: Oscillator
4.1 OSCSTAT bits: HFIOFR and HFIOFS
When HFINTOSC is selected, the HFIOFR and
the HFIOFS bits will become set when the
oscillator becomes ready and stable. Once these
bits are set, they become “stuck”, indicating that
HFINTOSC is always ready and stable. If the
HFINTOSC is disabled, the bits fail to be cleared.
Work around
None.
Affected Silicon Revisions
4.2 Clock Switching
When switching clock sources between INTOSC
clock source and an external clock source, one
corrupted instruction may be executed after the
switch occurs.
This issue does not affect the Two-Speed start-up
or the Fail-Safe Clock Monitor operation.
Work around
When switching from an external oscillator clock
source, first switch to 16 MHz HFINTOSC. Once
running at 16 MHz HFINTOSC, configure IRCF to
run at desired internal oscillator frequency.
When switching from an internal oscillator
(INTOSC) to an external oscillator clock source,
first switch to HFINTOSC High-Power mode (8
MHz or 16 MHz). Once running from HFINTOSC,
switch to the external oscillator clock source.
Affected Silicon Revisions
4.3 Oscillator Start-up Timer (OST) bit
During the Two-Speed Start-up sequence, the
OST is enabled to count 1024 clock cycles. After
the count is reached, the OSTS bit is set, and the
system clock is held low until the next falling edge
of the external crystal (LP, XT or HS mode), before
switching to the external clock source.
When an external oscillator is configured as
primary clock and Fail-Safe Clock mode is enabled
(FCMEN = 1), any of the following conditions will
result in the Oscillator Start-up Timer (OST) failing
to restart:
•MCLR
Reset
• Wake from Sleep
• Clock change from INTOSC to Primary Clock
This anomaly will manifest itself as a clock failure
condition for external oscillators, which takes
longer than the clock failure time-out period to
start.
Work around
None.
Affected Silicon Revisions
A2 A3 A5
XX
A2 A3 A5
XX
X
A2 A3 A5
XX
X
