2017 Microchip Technology Inc. DS80000725A-page 1
PIC16(L)F15356/75/76/85/86
The PIC16(L)F15356/75/76/85/86 family devices that
you have received conform functionally to the current
Device Data Sheet (DS40001866A), except for the
anomalies described in this document.
The silicon issues discussed in the following pages are
for silicon revisions with the Device and Revision IDs
listed in Table 1. The silicon issues are summarized in
Table 2.
The errata described in this document will be addressed
in future revisions of the PIC16(L)F15356/75/76/85/86
silicon.
Data Sheet clarifications and corrections start on page
4, following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
IDE and Microchip’s
programmers, debuggers, and emulation tools, which
are available at the Microchip corporate website
(www.microchip.com).
For example, to identify the silicon revision level
using MPLAB IDE in conjunction with a hardware
debugger:
1. Using the appropriate interface, connect the
device to the hardware debugger.
2. Open an MPLAB IDE project.
3. Configure the MPLAB IDE project for the
appropriate device and hardware debugger.
4. Based on the version of MPLAB IDE you are
using, do one of the following:
a) For MPLAB IDE 8, select Programmer >
Reconnect.
b) For MPLAB X IDE, select Window >
Dashboard and click the Refresh Debug
Tool Status icon ( ).
5. Depending on the development tool used, the
part number and Device Revision ID value
appear in the Output window.
The DEVREV values for the various PIC16(L)F15356/
75/76/85/86 silicon revisions are shown in Table 1.
Note: This document summarizes all silicon
errata issues from all revisions of silicon,
previous as well as current. Only the
issues indicated in the last column of
Table 2 apply to the current silicon
revision (A1).
Note: If you are unable to extract the silicon
revision level, please contact your local
Microchip sales office for assistance.
TABLE 1: SILICON DEVREV VALUES
Part Number Device ID
(1)
Revision ID for Silicon
Revision
(2)
A1
PIC16F15356 30B0h 2001h
PIC16LF15356 30B1h 2001h
PIC16F15375 30B2h 2001h
PIC16LF15375 30B3h 2001h
PIC16F15376 30B4h 2001h
PIC16LF15376 30B5h 2001h
PIC16F15385 30B6h 2001h
PIC16LF15385 30B7h 2001h
PIC16F15386 30B8h 2001h
PIC16LF15386 30B9h 2001h
Note 1: The Device IDs (DEVID and DEVREV) are located at addresses 8006h and 8005h, respectively. They are
shown in hexadecimal in the format “DEVID DEVREV”.
2: Refer to the “PIC16(L)F153XX Memory Programming Specification” (DS40001838) for detailed
information on Device and Revision IDs for your specific device.
PIC16(L)F15356/75/76/85/86 Family
Silicon Errata and Data Sheet Clarification
