PIC16F1614-I/SL数据手册
Page:
of 584 Go
若手册格式错乱，请下载阅览PDF原文件
2014-2016 Microchip Technology Inc. DS40001769B-page 2
PIC16(L)F1614/8
• Up to 17 I/O Pins and One Input-only Pin:
- Individually programmable pull-ups
- Slew rate control
- Interrupt-on-change with edge-select
- Two High Current Drive pins
• Peripheral Pin Select (PPS):
- Enables pin mapping of digital I/O
Intelligent Analog Peripherals
• 10-Bit Analog-to-Digital Converter (ADC):
- Up to 12 external channels
- Conversion available during Sleep
• Two Comparators (COMP):
- Low-Power/High-Speed mode
- Up to three external inverting inputs
- Fixed Voltage Reference at non-inverting
input(s)
- Comparator outputs externally accessible
• 8-Bit Digital-to-Analog Converter (DAC):
- 8-bit resolution, rail-to-rail
- Positive Reference Selection
• Voltage Reference:
- Fixed Voltage Reference (FVR): 1.024V,
2.048V and 4.096V output levels
• Zero-Cross Detect (ZCD):
- Detect when AC signal on pin crosses
ground
• Two High-Current Drive Pins:
- 100mA @ 5V
Clocking Structure
• 16 MHz Internal Oscillator:
- ±1% at calibration
- Selectable frequency range from 32 MHz to
31 kHz
• 31 kHz Low-Power Internal Oscillator
• 4x Phase-Locked Loop (PLL):
- For up to 32 MHz internal operation
• External Oscillator Block with:
- Three external clock modes up to 32 MHz
