PIC16(L)F1704/8
DS40001715D-page 2 2013-2015 Microchip Technology Inc.
Digital Peripheral Features (Continued)
Complementary Output Generator (COG):
- Push-Pull, Full Bridge, and Steering modes
- Dedicated Rise/Fall Input Triggers
- Dedicated Deadtime Delay Counters
- Dedicated Phase Delay Counters
- Dedicated Blanking Delay Counters
- Concurrent Auto-Shutdown Selection
Two Pulse Width Modulation (PWM) modules:
- 10-bit Duty-Cycle Control
Three Configurable Logic Cell (CLC) modules:
- Generate a selected function of up to four
inputs
- Combinational and State Logic
- External or Internal input/output pins
- Operation in Sleep
Peripheral Pin Select (PPS):
- Digital outputs mapped to any GPIO pin
- Digital inputs from any GPIO pin
- CLC input multiplexing
Analog Peripheral Features
Operational Amplifiers:
- Up to two configurable op amps
- Selectable internal and external channels
- High/Low selectable Gain Bandwidth Product
Two High-Speed Comparators:
- 60 ns response time
- Low-power/High-power mode
- Comparator outputs externally accessible
- Software hysteresis enable
Analog-to-Digital Converter (ADC) module
- 10-bit resolution, 12 channels
- Auto conversion start capability
- Conversion available during Sleep
8-Bit Digital-to-Analog Converter (DAC):
- Output available externally
- Positive and negative reference selection
- Internal connections to comparators,
op amps, Fixed Voltage Reference (FVR)
and ADC
Zero-Cross Detection Circuit:
- Constant Voltage Output
- Current Source/Sink
- Interrupt on Edge Detect
Voltage Reference module:
- Fixed Voltage Reference (FVR) with 1.024V,
2.048V and 4.096V output levels
PIC16(L)F170x Family Types
Device
Data Sheet Index
Program Memory
Flash (words)
Data SRAM
(bytes)
High-Endurance
Flash (bytes)
I/O’s
(2)
10-bit ADC (ch)
8-bit DAC
High-Speed/
Comparators
Op Amp
Zero Cross
Timers
(8/16-bit)
CCP
PWM
COG
EUSART
MSSP (I
2
C/SPI)
CLC
PPS
Debug
(1)
XLP
PIC16(L)F1703 (3) 2048 256 128 12 8 0 0 2 1 2/1 2 0 0 0 1 0 Y I/E Y
PIC16(L)F1704(1)4096512128128 1 2 2 1 4/1 221113YI/EY
PIC16(L)F1705 (2) 8192 1024 128 12 8 1 2 2 1 4/1 2 2 1 1 1 3 Y I/E Y
PIC16(L)F1707 (3) 2048 256 128 18 12 0 0 2 1 2/1 2 0 0 0 1 0 Y I/E Y
PIC16(L)F1708(1)409651212818121 2 2 1 4/1 221113YI/EY
PIC16(L)F1709 (2) 8192 1024 128 18 12 1 2 2 1 4/1 2 2 1 1 1 3 Y I/E Y
Note 1: Debugging Methods: (I) – Integrated on Chip; (H) – using Debug Header; E – using Emulation Header.
2: One pin is input-only.
Data Sheet Index: (Unshaded devices are described in this document.)
1: DS40001715 PIC16(L)F1704/8 Data Sheet, 14/20-Pin Flash, 8-bit Microcontrollers.
2: DS40001729 PIC16(L)F1705/9 Data Sheet, 14/20-Pin Flash, 8-bit Microcontrollers.
3: DS40001722 PIC16(L)F1703/7 Data Sheet, 14/20-Pin Flash, 8-bit Microcontrollers
Note: For other small form-factor package availability and marking information, please visit
http://www.microchip.com/packaging or contact your local sales office.
