PIC16(L)F1713/1716
DS80000592D-page 2 2014-2017 Microchip Technology Inc.
TABLE 2: SILICON ISSUE SUMMARY
Module Feature
Item
Number
Issue Summary
Affected
Revision
(1)
A1 A2
PORTS Pin Input Impedance 1.1 Pin leakage of RA3 may be high. X X
Comparator Low-Power Mode 2.1 Unexpected Low-Power mode
performance.
XX
Fixed Voltage
Reference (FVR)
4x Gain Amplifier 3.1 The output of the 4x gain amplifier is
4.25V.
XX
COG Blanking 4.1 Blanking may fail to release. X
EUSART Transmit 5.1 Duplicate Transmission. X
Master Synchronous
Serial Port (MSSP)
SPI Slave Mode 6.1 Slave select release during Sleep
corrupts data.
X
Master Synchronous
Serial Port (MSSP)
SPI Slave Mode 6.2 Receive data lost when Slave select
enable occurs just before Sleep
execution.
X
Master Synchronous
Serial Port (MSSP)
SPI Slave Mode 6.3 WCOL improperly set in Sleep. X
Note 1: Only those issues indicated in the last column apply to the current silicon revision.
