PIC16(L)F1717/8/9
DS40001740B-page 2 2014-2015 Microchip Technology Inc.
Clocking Structure:
• 16 MHz Internal Oscillator Block:
- ±1% at calibration
- Selectable frequency range from 0 to 32 MHz
• 31 kHz Low-Power Internal Oscillator
• External Oscillator Block with:
- Three crystal/resonator modes up to 20 MHz
- Two external clock modes up to 20 MHz
• Fail-Safe Clock Monitor
• Two-Speed Oscillator Start-up
• Oscillator Start-up Timer (OST)
Programming/Debug Features:
• In-Circuit Debug Integrated On-Chip
• Emulation Header for Advanced Debug:
- Provides trace, background debug and up to
32 hardware break points
• In-Circuit Serial Programming™ (ICSP™) via Two
Pins
PIC16(L)F171X Family Types
Device
Data Sheet Index
Program Memory
Flash (words)
Data SRAM
(bytes)
High Endurance Flash
(bytes)
I/Os
(2)
10-bit ADC (ch)
5/8-bit DAC
High-Speed/
Comparators
Op Amp
Zero Cross
Timers
(8/16-bit)
CCP
PWM
COG
EUSART
MSSP (I
2
C/SPI)
CLC
NCO
PPS
Debug
(1)
XLP
PIC16(L)F1713 (1) 4096 512 128 25 17 1/1 2 2 1 4/1 2 2 1 1 1 4 1 Y I/E Y
PIC16(L)F1716 (1) 8192 1024 128 25 17 1/1 2 2 1 4/1 2 2 1 1 1 4 1 Y I/E Y
PIC16(L)F1717 (2) 8192 1024 128 36 28 1/1 2 2 1 4/1 2 2 1 1 1 4 1 Y I/E Y
PIC16(L)F1718 (2) 16384 2048 128 25 17 1/1 2 2 1 4/1 2 2 1 1 1 4 1 Y I/E Y
PIC16(L)F1719 (2) 16384 2048
128 36 28 1/1 2 2 1 4/1 2 2 1 1 1 4 1 Y I/E Y
Note 1: Debugging Methods: (I) – Integrated on Chip; (H) – using Debug Header; E – using Emulation Header.
2: One pin is input-only.
Data Sheet Index: (Unshaded devices are described in this document.)
1: DS40001726 PIC16(L)F1713/6 Data Sheet, 28-Pin Flash, 8-bit Microcontrollers.
2: DS40001740 PIC16(L)F1717/8/9 Data Sheet, 28/40-Pin Flash, 8-bit Microcontrollers.
Note: For other small form-factor package availability and marking information, please visit
http://www.microchip.com/packaging or contact your local sales office.
