2014-2019 Microchip Technology Inc. DS40001775E-page 2
PIC16(L)F1764/5/8/9
Intelligent Analog Peripherals (Cont.)
• Voltage Reference:
- Fixed Voltage Reference (FVR): 1.024V,
2.048V and 4.096V output levels
• Zero-Cross Detector (ZCD):
- Detect high-voltage AC signal
• Programmable Ramp Generator (PRG):
- Slope compensation
- Ramp generation
• High-Current Drive I/Os:
- 100 mA capacity @ 5V
Clocking Structure
• 16 MHz Internal Oscillator:
- ±1% at calibration
- Selectable frequency range, 32 MHz to
31 kHz
• 31 kHz Low-Power Internal Oscillator
• 4x Phase-Locked Loop (PLL):
- For up to 32 MHz internal operation
• External Oscillator Block with:
- Three External Clock modes up to 32 MHz
TABLE 1: PIC16(L)F1764/5/8/9 FAMILY TYPES
Device
Data Sheet Index
Program Memory Flash
(Words/Kbytes)
High-Endurance Flash (B)
Data SRAM (Bytes)
I/O Pins
(2)
16-Bit Timers
8-Bit Timers w/HLT
Comparator
10-Bit ADC (ch)
5/10-Bit DAC
CCP
10/16-Bit PWM
COG
Data Signal Modulator
CLC
Op Amp
Zero-Cross Detect
Programmable Ramp Gen
High-Current I/Os
Peripheral Pin Select
EUSART
I
2
C/SPI
Debug
(1)
PIC16(L)F1764 (A) 4096/7 128 512 12 3 1/3 2 8 1/1 1 1/1 1 1 3 1 1 1 2 Y 1 1 I/H
PIC16(L)F1765 (A) 8192/14 128 1024 12 3 1/3 2 8 1/1 1 1/1 1 1 3 1 1 1 2 Y 1 1 I/H
PIC16(L)F1768 (A) 4096/7 128 512 18 3 1/3 4 12 2/2 2 2/2 2 2 3 2 1 2 2 Y 1 1 I/H
PIC16(L)F1769 (A) 8192/14 128 1024 18 3 1/3 4 12 2/2 2 2/2 2 2 3 2 1 2 2 Y 1 1 I/H
Note 1: Debugging Methods: (I) – Integrated on Chip; (H) – via ICD Header; E – Emulation Product.
2: One pin is input-only.
Data Sheet Index: (Unshaded devices are described in this document.)
A. DS-40001775 PIC16(L)F1764/5/8/9 Data Sheet, 14/20-Pin 8-Bit Flash Microcontrollers.
Note: For other small form factor package availability and marking information, please visit
http://www.microchip.com/packaging or contact your local sales office.
TABLE 2: PACKAGES
Packages PDIP SOIC TSSOP QFN SSOP
PIC16(L)F1764
PIC16(L)F1765
PIC16(L)F1768
PIC16(L)F1769
Note: Pin details are subject to change.
