2010 Microchip Technology Inc. DS80243M-page 1
PIC16F631/677/685/687/689/690
The PIC16F631/677/685/687/689/690 family devices
that you have received conform functionally to the
current Device Data Sheet (DS41262E), except for the
anomalies described in this document.
The silicon issues discussed in the following pages are
for silicon revisions with the Device and Revision IDs
listed in Table 1. The silicon issues are summarized in
Table 2 through Table 6.
The errata described in this document will be addressed
in future revisions of the PIC16F631/677/685/687/689/
690 silicon.
Data Sheet clarifications and corrections start on page
12, following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
IDE and Microchip’s
programmers, debuggers, and emulation tools, which
are available at the Microchip corporate web site
(www.microchip.com).
For example, to identify the silicon revision level using
MPLAB IDE in conjunction with MPLAB ICD 2,
MPLAB ICD 3, PICkit™ 2 or PICkit™ 3:
1. Using the appropriate interface, connect the
device to the MPLAB ICD 2 programmer/
debugger, PICkit™ 2 or PICkit™ 3.
2. From the main menu in MPLAB IDE, select
C
onfigure>Select Device, and then select the
target part number in the dialog box.
3. Select the MPLAB hardware tool
(Programmer
>Select Tool).
4. Perform a “Connect” operation to the device
(Programmer
>Connect). Depending on the
development tool used, the part number and
Device Revision ID value appear in the Output
window.
The Device ID values for the various devices and
silicon revisions are shown in Table 1.
Note: This document summarizes all silicon
errata issues from all revisions of silicon,
previous as well as current. Only the
issues indicated in the last column of
Table 2 through Table 6 apply to the
current silicon revision.
Note: If you are unable to extract the silicon
revision level, please contact your local
Microchip sales office for assistance.
TABLE 1: SILICON DEVREV VALUES
Part Number Device ID
(1)
Revision ID for Silicon Revision
(2)
A1 A3 A4 A5 A6
PIC16F631 142x 1
PIC16F677 132x 1
PIC16F685 04Ax 3456
PIC16F687 132x 3 4 5 6
PIC16F689 134x 3 4 5 6
PIC16F690 134x 3 4 5 6
Note 1: The device and revision data is stored in the Device ID located at 2006h in program memory.
2: Refer to the “PIC12F6XX/16F6XX Memory Programming Specification” (DS41204) for detailed
information.
PIC16F631/677/685/687/689/690 Family
Silicon Errata and Data Sheet Clarification
