2008-2013 Microchip Technology Inc. DS80000382K-page 1
PIC16(L)F72X
The PIC16(L)F72X family devices that you have
received conform functionally to the current Device Data
Sheet (DS41341E), except for the anomalies described
in this document.
The silicon issues discussed in the following pages are
for silicon revisions with the Device and Revision IDs
listed in Table 1. The silicon issues are summarized in
Table 2.
The errata described in this document will be addressed
in future revisions of the PIC16(L)F72X silicon.
Data Sheet clarifications and corrections start on page 7,
following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
IDE and Microchip’s
programmers, debuggers, and emulation tools, which
are available at the Microchip corporate web site
(www.microchip.com).
For example, to identify the silicon revision level
using MPLAB IDE in conjunction with a hardware
debugger:
1. Using the appropriate interface, connect the
device to the hardware debugger.
2. Open an MPLAB IDE project.
3. Configure the MPLAB IDE project for the
appropriate device and hardware debugger.
4. Based on the version of MPLAB IDE you are
using, do one of the following:
a) For MPLAB IDE 8, select Programmer >
Reconnect.
b) For MPLAB X IDE, select Window >
Dashboard and click the Refresh Debug
Tool Status icon ( ).
5. Depending on the development tool used, the
part number and Device Revision ID value
appear in the Output window.
The DEVREV values for the various PIC16(L)F72X
silicon revisions are shown in Tabl e 1.
Note: This document summarizes all silicon
errata issues from all revisions of silicon,
previous as well as current. Only the
issues indicated in the last column of
Table 2 apply to the current silicon
revision (AK).
Note: If you are unable to extract the silicon
revision level, please contact your local
Microchip sales office for assistance.
TABLE 1: SILICON DEVREV VALUES
Part Number Device ID
(1)
Revision ID for Silicon Revision
(2)
A7 A9 AA AB AC AD AK
PIC16F722 01 1000 100x xxxx 0x7 0x9 0xA 0xB 0xC 0xD 0x12
PIC16LF722 01 1001 100x xxxx 0x7 0x9 0xA 0xB 0xC 0xD 0x12
PIC16F723 01 1000 011x xxxx 0x7 0x9 0xA 0xB 0xC 0xD 0x12
PIC16LF723 01 1001 011x xxxx 0x7 0x9 0xA 0xB 0xC 0xD 0x12
PIC16F724 01 1000 010x xxxx 0x7 0x9 0xA 0xB 0xC 0xD 0x12
PIC16LF724 01 1001 010x xxxx 0x7 0x9 0xA 0xB 0xC 0xD 0x12
PIC16F726 01 1000 001x xxxx 0x7 0x9 0xA 0xB 0xC 0xD 0x12
PIC16LF726 01 1001 001x xxxx 0x7 0x9 0xA 0xB 0xC 0xD 0x12
PIC16F727 01 1000 000x xxxx 0x7 0x9 0xA 0xB 0xC 0xD 0x12
PIC16LF727 01 1001 000x xxxx 0x7 0x9 0xA 0xB 0xC 0xD 0x12
Note 1: The Device ID is located at 2006h. The five Least Significant bits comprise the revision ID.
2: Refer to the “PIC16F72X Memory Programming Specification” (DS41332) for detailed information on
Device and Revision IDs for your specific device.
PIC16(L)F72X Family
Silicon Errata and Data Sheet Clarification
