DS30430C/F84/E1A1-page 2
1998 Microchip Technology Inc.
PIC16F84
Clarifications/Corrections to the Data Sheet:
In the Device Data Sheet (DS30430
C
), the following clar-
ifications and corrections should be noted.
1. Module: Data EEPROM
In the PIC16F8X Data Sheet (DS30430
B
), the following
clarifications and corrections should be noted.
a) Erase/Write Cycle Time for Data EEPROM should
be changed from 10 ms maximum to 20 ms maxi-
mum, as shown in Table 1.
TABLE 1: DC SPECIFICATION LIMITS THAT VARY FROM DATA SHEET
2. Module: Device Idd
a) The maximum device I
DD
in the LP oscillaor mode
(at 32KHz, 2.0 V, and WDT disabled) should be
changed from 32
µ
A maximum to 45
µ
A maximum,
as shown in Table 1.
TABLE 2: DC SPECIFICATION LIMITS THAT VARY FROM DATA SHEET
Parameter
No.
Sym. Characteristic
Actual Data Data Sheet
Units
Typ Max Typ Max
D122 T
DEW
Erase Write Cycle Time 10 20 * — 10 ms
* This parameter is characterized but not tested
Parameter
No.
Sym. Characteristic
Actual Data Data Sheet
Units
Typ Max Typ Max
D014 I
DD
Supply Current 15 45 15 32
µ
A
