2007-2013 Microchip Technology Inc. DS80000302H-page 1
PIC16F88X
The PIC16F88X family devices that you have received
conform functionally to the current Device Data Sheet
(DS41291G), except for the anomalies described in
this document.
The silicon issues discussed in the following pages are
for silicon revisions with the Device and Revision IDs
listed in Tab le 1. The silicon issues are summarized in
Table 2, Table 3 and Table 4.
The errata described in this document will be addressed
in future revisions of the PIC16F88X silicon.
Data Sheet clarifications and corrections start on page
14, following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
IDE and Microchip’s
programmers, debuggers, and emulation tools, which
are available at the Microchip corporate web site
(www.microchip.com).
For example, to identify the silicon revision level
using MPLAB IDE in conjunction with a hardware
debugger:
1. Using the appropriate interface, connect the
device to the hardware debugger.
2. Open an MPLAB IDE project.
3. Configure the MPLAB IDE project for the
appropriate device and hardware debugger.
4. Based on the version of MPLAB IDE you are
using, do one of the following:
a) For MPLAB IDE 8, select Programmer >
Reconnect.
b) For MPLAB X IDE, select Window >
Dashboard and click the Refresh Debug
Note: This document summarizes all silicon
errata issues from all revisions of silicon,
previous as well as current. Only the
issues indicated in the last column of
Table 2, Table 3 and Table 4 apply to the
current silicon revision (A0 or A2, as
applicable).
TABLE 1: SILICON DEVREV VALUES
Part Number Device ID
(1)
Revision ID for Silicon Revision
(2)
A0 A2
PIC16F882 2000h 00h
PIC16F883 2020h 00h
PIC16F884 2040h 00h
PIC16F886 2060h
02h
PIC16F887 2080h 02h
Note 1: The device and revision data is stored in the Device ID located at 2006h in program memory.
2: Refer to the “PIC16F88X Memory Programming Specification” (DS41287) for detailed information.
PIC16F88X Family
Silicon Errata and Data Sheet Clarification
