2006-2014 Microchip Technology Inc. DS80000285D-page 1
PIC18F2221/2321/4221/4321
The PIC18F2221/2321/4221/4321 devices that you
have received conform functionally to the current
Device Data Sheet (DS39689F), except for the anom-
alies described in this document.
The silicon issues discussed in the following pages are
for silicon revisions with the Device and Revision IDs
listed in Table 1. The silicon issues are summarized in
Table 2.
The errata described in this document will be addressed
in future revisions of the PIC18F2221/2321/4221/4321
silicon.
Data Sheet clarifications and corrections start on page
5, following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
IDE and Microchip’s pro-
grammers, debuggers, and emulation tools, which are
available at the Microchip corporate web site
(www.microchip.com).
For example, to identify the silicon revision level
using MPLAB IDE in conjunction with a hardware
debugger:
1. Using the appropriate interface, connect the
device to the hardware debugger.
2. Open an MPLAB IDE project.
3. Configure the MPLAB IDE project for the
appropriate device and hardware debugger.
4. Based on the version of MPLAB IDE you are
using, do one of the following:
a) For MPLAB IDE 8, select Programmer >
Reconnect.
b) For MPLAB X IDE, select Window >
Dashboard and click the Refresh Debug
Tool Status icon ( ).
5. Depending on the development tool used, the
part number and Device Revision ID value
appear in the Output window.
The DEVREV values for the various PIC18F2221/2321/
4221/4321 silicon revisions are shown in Tabl e 1.
Note: This document summarizes all silicon
errata issues from all revisions of silicon,
previous as well as current. Only the
issues indicated in the last column of
Table 2 apply to the current silicon
revision (B3).
Note: If you are unable to extract the silicon
revision level, please contact your local
Microchip sales office for assistance.
TABLE 1: SILICON DEVREV VALUES
Part Number Device ID
(1)
Revision ID for Silicon Revision
(2)
B2 B3
PIC18F2221 216h
2h 3h
PIC18F2321 212h
PIC18F4221 214h
PIC18F4321 210h
Note 1: The Device IDs (DEVID and DEVREV) are located at the last two implemented addresses of configuration
memory space. They are shown in hexadecimal in the format “DEVID DEVREV”.
2: Refer to the “PIC18F2XXX/4XXX Family Flash Microcontroller Programming Specification” (DS39622) for
detailed information on Device and Revision IDs for your specific device.
PIC18F2221/2321/4221/4321 Family
Silicon Errata and Data Sheet Clarification
