PIC18F23/43K20
DS80000469E-page 6 2009-2015 Microchip Technology Inc.
Data Sheet Clarifications
The following typographical corrections and
clarifications are to be noted for the latest version of the
device data sheet (DS41303H):
1. Module: Product Identification System
The temperature range values have been
corrected.
PRODUCT IDENTIFICATION SYSTEM
To order or obtain information, e.g., on pricing or delivery, refer to the factory or the listed sales office.
Note: Corrections are shown in bold. Where
possible, the original bold text formatting
has been removed for clarity.
PART NO.
X /XX XXX
PatternPackageTemperature
Range
Device
Device: PIC18F23K20; PIC18F43K20; PIC16F884; PIC18F26K20;
PIC16F886; PIC16F887; PIC18F45K20; PIC18F46K20.
Tape and Reel
Option:
Blank = Standard packaging (tube or tray)
T = Tape and Reel
(1)
Temperature
Range:
I= -40C to +85C(Industrial)
E= -40C to +125C(Extended)
Package: PT = TQFP (Thin Quad Flatpack)
SS = SSOP
SO = SOIC
SP = SPDIP (Skinny Plastic DIP)
P=PDIP
ML = QFN
MV = UQFN
Pattern: QTP, SQTP, Code or Special Requirements
(blank otherwise)
Examples:
a) PIC18F45K20 - E/P 301 = Industrial temp.,
PDIP package, QTP pattern #301.
b) PIC18F23K20 - I/SO = Industrial temp., SOIC
package.
c) PIC16F887 - E/P = Extended temp., PDIP
package.
d) PIC18F46K20 - I/PT = Industrial temp., TQFP
package, tape and reel.
Note 1: Tape and Reel identifier only appears in the
catalog part number description. This
identifier is used for ordering purposes and
is not printed on the device package. Check
with your Microchip Sales Office for package
availability with the Tape and Reel option.
[X]
(1)
Tape and Reel
Option
