PIC18F2620-I/SP 其他数据使用手册 - Microchip（微芯）
制造商:
Microchip（微芯）
分类:
微控制器
封装:
DIP-28
描述:
PIC18F2525/2620/4525/4620 8 位微控制器Microchip 的 PIC18F 微控制器是 Microchip 产品线中功能最强大的 8 位设备。 该系列包含的 CAN、LIN 和以太网功能是完整系列外围设备的一部分，可满足嵌入式应用和版本的需求，采用 XLP（极低功耗）技术，用于功耗为关键考量的应用。 PIC18F2525/2620/4525/4620 系列微控制器基于 Microchip 的 PIC18 体系结构，提供 31 级 硬件堆栈和 75 指令。 这些 MCU 提供高达 10 个 MIPS、多达 64 kb 的程序存储器、多达 3968 kb 的 RAM 和 124 kb 的数据 EEPROM。 板载可配置 RC 振荡器。### 微控制器功能40 MHz 最大 CPU 速度 75 指令 - 通过扩展指令集支持 83 指令 31 级硬件堆栈 内部振荡器 - 可选频率范围 8 mHz 至 31 kHz 25 个输入/输出引脚 - PIC18F2525/2620 型号 36 个输入/输出引脚 - PIC18F4525/4620 型号 nanoWatt 技术 通电重置 (POR) 通电计时器 (PWRT) 振荡器启动计时器 (OST) 掉电重置 (BOR) 延长监控计时器 (WDT) 高电压/低电压检测 (HLVD) 模块 在线串行编程 (ICSP) 在线调试 (ICD) ### 外设10 位模拟到数字转换器 (ADC) - PIC18F2525/2620 10 通道；PIC18F4525/4620 13 通道 采集、比较、PWM 模块 - PIC18F2525/2620 x 2、PIC18F4525/4620 x 1 一个增强型采集、比较、PWM 模块 - 仅 PIC18F4525/4620 型号 两个比较器 一个 8 位计时器 三个 16 位计时器 主同步串行端口 (MSSP) 模块，带有 SPI 和 I2C 增强型通用同步异步接收器发射器 (EUSART) ### PIC18 微控制器展开
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
典型应用电路图在P31
型号编码规则在P3P4P6P8P10P11P12P13P14P16P17P18
导航目录
PIC18F2620-I/SP数据手册
Page:
of 68 Go
若手册格式错乱，请下载阅览PDF原文件
Microchip Development Systems Ordering Guide
DS30177M-page 4 2000 Microchip Technology Inc.
MPLAB
®
In-Circuit Emulator (ICE) Ordering Instructions
How Do I Order MPLAB-ICE?
Ordering MPLAB-ICE as easy as 1, 2, and 3!
1. Pick your PICmicro
®
MCU device.
2. Pick your PICmicro MCU package.
3. Find the right line on the next few pages for
MPLAB-ICE part numbers. You’re ready to order.
A Complete MPLAB-ICE System
MPLAB-ICE is a modular emulator system with
interchangeable components allowing the system to be
easily configured to emulate different PICmicro
microcontrollers (MCU). Since this emulator supports
package-specific emulation, customers need to know
which device and package they intend to emulate.
Then, the customer can use the MPLAB-ICE Cross
Reference Parts List starting onpage 5 to identify the
part numbers required to complete an MPLAB-ICE
system. A complete system consists of:
1. An emulator pod (including among other things
the host-to-pod parallel cable and power supply).
2. A processor module (including the flex cable
circuit).
3. A device adapter.
4. An optional transition socket.
An MPLAB-ICE system is ordered as separate
components. Knowing the terms will make it easy to
order and use the MPLAB-ICE system. Read more
about each component.
1. Emulator Pod
MPLAB-ICE 2000 is the full-featured emulator pod
containing a main board and an additional board for
expanded trace memory and complex control logic.
MPLAB-ICE 2000 comes with a standard parallel
interface cable that connects the pod to the parallel
port of the PC.
2. Processor Module
The processor module is a PICmicro MCU, device-
specific module that is inserted into the emulator pod.
The processor module contains the emulator chip,
logic, and low-voltage circuitry. A flex cable extends
from the processor module and is connected to the
device adapter at the target application.
3. Device Adapter
The device adapter provides a common interface for
the PICmicro MCU being emulated. The device
adapter provides emulation support for standard DIP
and PLCC styles. For emulation support of other
packages, a transition socket is needed along with the
device adapter. This adapter contains a special device
that provides an oscillator clock allowing the user to
accurately emulate the RC characteristics of the
PICmicro MCU.
4. Transition Socket
The transition sockets are available in various styles to
allow the common device adapter to be translated to
support surface-mount packages, such as SOIC,
SSOP, PQFP, and TQFP.
Emulator Pod
Processor Module
Device Adapter
Transition Socket
