PIC18F26/45/46K40
DS80000712B-page 2 2016 Microchip Technology Inc.
TABLE 2: SILICON ISSUE SUMMARY
Module Feature
Item
No.
Issue Summary
Affected Revisions
(1)
A3 A4
Analog-to-Digital
Converter (ADC)
ADC Conversion 1.1 Delay of one instruction cycle
required prior to setting the ADGO bit
when using ADCRC as the ADCC
clock source.
X
Analog-to-Digital
Converter (ADC)
Computation
Overflow Bit
1.2 The Computation Overflow bit may
be erroneously set by the ADFLTR.
X
Analog-to-Digital
Converter (ADC)
ADCRC Oscillator
Operation in Sleep
1.3 The ADCRC oscillator does not stop
after conversion is complete in Sleep
mode.
XX
Analog-to-Digital
Converter (ADC)
ADC Conversion
with FVR
1.4 Using the FVR as the ADC positive
voltage reference can cause miss-
ing codes.
XX
PIC18 Debug
Executive
Data Write Match
Breakpoints
2.1 Data write match breakpoints do not
work when used on a location GSR
space.
X
PIC18 Core TBLRD 3.1 TBLRD requires NVMREG value to
point to appropriate memory.
X
Program Flash
Memory
Endurance of PFM
Cell
4.1 Endurance of the PFM cell is lower
than specified.
XX
MSSP SMBus 2.0 Voltage
Level
5.1 Input low-voltage threshold level
depends on V
DD.
XX
Note 1: Only those issues indicated in the last column apply to the current silicon revision.
