2008-2015 Microchip Technology Inc. DS80000421B-page 1
PIC18F2450/4450
The PIC18F2450/4450 Rev. A4 parts you have
received conform functionally to the Device Data Sheet
(DS39760D), except for the anomalies described
below. Any Data Sheet Clarification issues related to
the PIC18F2450/4450 will be reported in a separate
Data Sheet errata. Please check the Microchip web site
for any existing issues.
The following silicon errata apply only to
PIC18F2450/4450 devices with these Device/Revision
IDs:
All of the issues listed here will be addressed in future
revisions of the PIC18F2450/4450 silicon.
1. Module: Enhanced Universal
Synchronous Asynchronous
Receiver Transmitter (EUSART)
In rare situations when interrupts are enabled,
unexpected results may occur if:
• The EUSART is disabled (the SPEN bit,
RCSTA <7>, = 0)
• The EUSART is re-enabled (RCSTA <7> = 1)
• A 2-cycle instruction is executed
Work around
Add a 2-TCY delay after re-enabling the EUSART.
1. Disable Receive Interrupts (RCIE bit,
PIE1<5>, = 0).
2. Disable the EUSART (RCSTA <7>, = 0).
3. Re-enable the EUSART (RCSTA <7> = 1).
4. Re-enable Receive Interrupts (PIE1<5> = 1).
(This is the first TCY delay.)
5. Execute an NOP instruction.
(This is the second T
CY delay.)
Date Codes that pertain to this issue:
All engineering and production devices.
Part Number Device ID Revision ID
PIC18F2450 0010 0100 001 0 0011
PIC18F4450 0010 0100 000 0 0011
The Device IDs (DEVID1 and DEVID2) are located at
addresses 3FFFFEh:3FFFFFh in the device’s
configuration space. They are shown in binary in the
format “DEVID2 DEVID1”.
PIC18F2450/4450 Rev. A4 Silicon Errata
