© 2006 Microchip Technology Inc. DS80266A-page 1
PIC18F2450/4450
The PIC18F2450/4450 (Rev. A1) parts you have
received conform functionally to the Device Data Sheet
(DS39760A), except for the anomalies described
below. Any data sheet clarification issues related to this
device will be reported in a separate data sheet errata.
Please check the Microchip web site for any existing
issues.
The following silicon errata apply only to
PIC18F2450/4450 devices with these Device/Revision
IDs:
The Device IDs (DEVID1 and DEVID2) are located at
addresses 3FFFFEh:3FFFFFh in the device’s configu-
ration space. They are shown in hexadecimal in the
format “DEVID2 DEVID1”.
1. Module: EUSART
In Asynchronous mode, the reception can get
corrupted if any bit of the TXSTA register is
modified during a reception.
Work around
Maintain CSRC (TXSTA<7>) and SYNC
(TXSTA<4>) bits as ‘0’. Though the CSRC
(TXSTA<7>) bit is a don’t care in Asynchronous
mode, make sure that this bit is not set.
2. Module: A/D (Offset)
The A/D offset is greater than the specified limit in
Table 21-17 of the Device Data Sheet. The
updated conditions and limits are shown in bold
text in Table 1.
Work around
There are three work arounds:
1. Configure the A/D to use the V
REF+ and VREF-
pins for the voltage references. This is done by
setting the VCFG<1:0> bits (ADCON1<5:4>).
2. Perform a conversion on a known voltage
reference voltage and adjust the A/D result in
software.
3. Increase system clock speed and adjust A/D
settings accordingly. Higher system clock
frequencies decrease offset error.
TABLE 1: A/D CONVERTER CHARACTERISTICS (PIC18F2450/4450)
Part Number Device ID Revision ID
PIC18F2450 01 0100 001 00001
PIC18F4450 01 0100 000 00001
Param
No.
Symbol Characteristic Min Typ Max Units Conditions
A06A E
OFF Offset Error ——<±1.5 LSb VREF = VREF+ and VREF-
A06 E
OFF Offset Error — — <±3.5 LSb VREF = VSS and VDD
PIC18F2450/4450 Rev. A1 Silicon Errata
