Visit our web site for additional product information and to locate your local sales office.
Microchip Technology Inc. • 2355 W. Chandler Blvd. • Chandler, AZ 85224-6199
Information subject to change. The Microchip name and logo, the Microchip logo, MPLAB, PIC and PICmicro are registered trademarks of Microchip Technology Incorporated in the U.S.A. and other
countries. Application Maestro, ICSP, MiWi, PICkit, PICDEM, PICDEM.net, PICtail, REAL ICE and ZENA are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. All other
trademarks mentioned herein are property of their respective companies. © 2006, Microchip Technology Incorporated. All Rights Reserved. Printed in the U.S.A. 12/06
DS39673C
*DS39673C*
www.microchip.com/developmenttools
LCD Segmented Display (www.microchip.com/LCD)
PICDEM™ LCD 2 Demonstration Board (DM163030)
The PICDEM LCD 2 board demonstrates the features of
the LCD Flash 28, 40, 64 and 80-pin PIC microcontrollers.
The board is populated with the PIC18F85J90 MCU and
other devices are supported via a separate pack of
Plug-in Modules (MA160011). A sample 3V LCD glass
display is included for custom prototyping and can
demonstrate the PIC18F85J90 boost and contrast
capability. The board ships with demo code and can
operate with a lithium coin cell.
Ethernet Technology (www.microchip.com/Ethernet)
PICDEM.net™ 2 Development Board (DM163024)
The PICDEM.net 2 Board is an Ethernet development
board supporting both the popular ENC28J60 Ethernet
Controller and the single-chip Ethernet microcontroller
family, the PIC18F97J60. Using Microchip’s free TCP/IP
stack and this board, a web server can be developed
showcasing the capability to remote monitor and control
embedded applications over the Internet. Features include
2 x RJ-45 Ethernet connectors, PICtail™ connector, LCD
display, ICSP™/MPLAB ICD 2 interface, programmable
buttons/LEDs, temperature sensor, RS-232/RS-485
interface and a real time clock.
CAN Technology (www.microchip.com/CAN)
PICDEM™ CAN-LIN 2, 3 (DM163011, DM163015)
Microchip offers two similar PICDEM
CAN-LIN Demo boards to support different
PIC microcontrollers. All demonstrate the
main features of the devices, especially
those features of the integrated CAN
module. The board also employs a LIN subnetwork using
Microchip’s PIC16C43X and PIC18F320 devices families.
Motor Control (www.microchip.com/MC)
PICDEM™ MC Demonstration Board (DM183011)
The PICDEM MC Demo Board includes everything needed
to evaluate the high-performance PIC18FXX31 MCUs for
motor control design. The board supports motors up to
800 watts, with complete isolation between power and
control circuits. This enables connection to debuggers and
emulators when high power is connected. The development
board comes with pre-programmed PIC18F2431 and
PIC18F4431 devices.
PICDEM™ MC Low Voltage (DM183021)
This board offers a cost-effective method
of evaluating and developing sensored or
sensorless brushless DC (BLDC) motor
control applications. The board supports
28-pin, PIC18 microcontrollers and is
capable of controlling motors rated up
to 48V and 2.2 amps. Pre-programmed PIC18F2431 and
dsPIC30F3010 devices are included.
nanoWatt Technology (www.microchip.com/LowPower)
Low Power Demonstration Board (DM163026)
This board uses the PIC18F4620 for demonstrating
nanoWatt features and implementing system power
reduction techniques. Included on the board are a fully
functional ultrasonic range fi nder with LCD display, a DC
boost circuit, USART, test points to measure system and
PIC power consumption, three switches, 2 LEDs and a
Microchip TC1047A temperature sensor. Three self-paced,
step-by-step lab exercises are included on CD-ROM.
FEATURED DEBUGGERS & PROGRAMMERS:
MPLAB® ICD 2 In-Circuit Debugger (DV164005)
A low-cost real-time debugger and programmer
that works with all of the PIC18 Flash
microcontrollers.
MPLAB® PM3 Programmer (DV007004)
This sophisticated universal programmer supports all
PIC18F devices.
PICkit™ 2 Development Programmer (PG164120)
An small, easy-to-use starter kit that enables users to start
writing code and programming with PIC microcontrollers.
The programmer interfaces to PICkit demo boards including
PIC18 J-series and K-series devices.
MPLAB® REAL ICE™ (DV244005)
Microchip’s latest high speed In-Circuit Emulator
system for debugging and programming Microchip Flash
microcontroller devices.
