2009-2013 Microchip Technology Inc. DS80000435K-page 1
PIC18F46J11
The PIC18F46J11 family devices that you have received
conform functionally to the current Device Data Sheet
(DS39932D), except for the anomalies described in this
document.
The silicon issues discussed in the following pages are
for silicon revisions with the Device and Revision IDs
listed in Table 1. The silicon issues are summarized in
Table 2.
The errata described in this document will be addressed
in future revisions of the PIC18F46J11 family silicon.
Data Sheet clarifications and corrections start on page 9,
following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
IDE and Microchip’s
programmers, debuggers, and emulation tools, which
are available at the Microchip corporate web site
(www.microchip.com).
For example, to identify the silicon revision level
using MPLAB IDE in conjunction with a hardware
debugger:
1. Using the appropriate interface, connect the
device to the hardware debugger.
2. Open an MPLAB IDE project.
3. Configure the MPLAB IDE project for the
appropriate device and hardware debugger.
4. Based on the version of MPLAB IDE you are
using, do one of the following:
a) For MPLAB IDE 8, select Programmer >
Reconnect.
b) For MPLAB X IDE, select Window >
Dashboard and click the Refresh Debug
Tool Status icon ( ).
5. Depending on the development tool used, the
part number and Device Revision ID value
appear in the Output window.
The DEVREV values for the various PIC18F46J11
family silicon revisions are shown in Tabl e 1.
Note: This document summarizes all silicon
errata issues from all revisions of silicon,
previous as well as current. Only the issues
indicated in the last column of Ta b le 2 apply
to the current silicon revision (A4).
Note: If you are unable to extract the silicon
revision level, please contact your local
Microchip sales office for assistance.
TABLE 1: SILICON DEVREV VALUES
Part Number Device ID
(1)
Revision ID for Silicon Revision
(2)
A2 A4
PIC18F24J11 0x26Ch
2h 4h
PIC18F25J11 0x26Dh
PIC18F26J11 0x26Eh
PIC18F44J11 0x26Fh
PIC18F45J11 0x270h
PIC18F46J11 0x271h
PIC18LF24J11 0x272h
PIC18LF25J11 0x273h
PIC18LF26J11 0x274h
PIC18LF44J11 0x275h
PIC18LF45J11 0x276h
PIC18LF46J11 0x277h
Note 1: The Device IDs (DEVID and REVID) are located at the last two implemented addresses of configuration memory space.
They are shown in hexadecimal in the format, “DEVID:REVID”.
2: Refer to the “PIC18F2XJXX/4XJXX Family Flash Microcontroller Programming Specification” (DS39687) for detailed
information on Device and Revision IDs for your specific device.
PIC18F46J11 Family
Silicon Errata and Data Sheet Clarification
