2011-2015 Microchip Technology Inc. DS80000522F-page 1
PIC24FV32KA304 FAMILY
The PIC24FV32KA304 family devices that you have
received conform functionally to the current Device
Data Sheet (DS39995D), except for the anomalies
described in this document.
The silicon issues discussed in the following pages are
for silicon revisions with the Device and Revision IDs
listed in Table 1. The silicon issues are summarized in
Table 2.
The errata described in this document will be addressed
in future revisions of the PIC24FV32KA304 family
silicon.
Data sheet clarifications and corrections start on Page 6,
following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
IDE and Microchip’s pro-
grammers, debuggers and emulation tools, which are
available at the Microchip corporate web site
(www.microchip.com).
For example, to identify the silicon revision level using
MPLAB IDE in conjunction with MPLAB ICD 2 or
PICkit™ 3:
1. Using the appropriate interface, connect the
device to the MPLAB ICD 2 programmer/
debugger or PICkit™ 3.
2. From the main menu in MPLAB IDE, select
Con
figure>Select Device, and then select the
target part number in the dialog box.
3. Select the MPLAB hardware tool
(Debugger>Select Tool
).
4. Perform a “Connect” operation to the device
(Debugger>Connect
). Depending on the devel-
opment tool used, the part number and Device
Revision ID value appear in the Output window.
The DEVREV values for the various PIC24FV32KA304
family silicon revisions are shown in Ta b l e 1.
Note: This document summarizes all silicon
errata issues from all revisions of silicon,
previous as well as current. Only the issues
indicated in the last column of Table 2
apply to the current silicon revision (A7).
Note: If you are unable to extract the silicon
revision level, please contact your local
Microchip sales office for assistance.
TABLE 1: SILICON DEVREV VALUES
Part Number Device ID
(1)
Revision ID for Silicon
Revision
(2)
Part Number Device ID
(1)
Revision ID for
Silicon Revision
(2)
A4 A6 A7 A4 A6 A7
PIC24F32KA304 4516h
0004h 0006h 00007h
PIC24FV32KA304 4517h
0004h 0006h 0007h
PIC24F32KA302 4512h PIC24FV32KA302 4513h
PIC24F32KA301 4518h PIC24FV32KA301 4519h
PIC24F16KA304 4506h PIC24FV16KA304 4507h
PIC24F16KA302 4502h PIC24FV16KA302 4503h
PIC24F16KA301 4508h PIC24FV16KA301 4509h
Note 1: The Device IDs (DEVID and DEVREV) are located at the last two implemented addresses of configuration
memory space. They are shown in hexadecimal in the format, “DEVID DEVREV”.
2: Refer to the “PIC24FXXKA1XX/FVXXKA3XX Family Flash Programming Specifications” (DS39919) for
detailed information on Device and Revision IDs for your specific device.
PIC24FV32KA304 Family
Silicon Errata and Data Sheet Clarification
