2011-2014 Microchip Technology Inc. DS80000534D-page 1
PIC24F16KL402 FAMILY
The PIC24F16KL402 family devices that you have
received conform functionally to the current Device
Data Sheet (DS30001037C), except for the anomalies
described in this document.
The silicon issues discussed in the following pages are
for silicon revisions with the Device and Revision IDs
listed in Table 1. The silicon issues are summarized in
Table 2.
The errata described in this document will be addressed
in future revisions of the PIC24F16KL402 family silicon.
Data Sheet clarifications and corrections start on Page 4,
following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
IDE and Microchip’s pro-
grammers, debuggers, and emulation tools, which are
available at the Microchip corporate web site
(www.microchip.com).
For example, to identify the silicon revision level using
MPLAB IDE in conjunction with MPLAB ICD 2 or
PICkit™ 3:
1. Using the appropriate interface, connect the
device to the MPLAB ICD 2 programmer/
debugger or PICkit™ 3.
2. From the main menu in MPLAB IDE, select
Con
figure>Select Device, and then select the
target part number in the dialog box.
3. Select the MPLAB hardware tool
(Debugger>Select Tool
).
4. Perform a “Connect” operation to the device
(Debugger>Connect
). Depending on the devel-
opment tool used, the part number and Device
Revision ID value appear in the Output window.
The DEVREV values for the various PIC24F16KL402
family silicon revisions are shown in Table 1.
Note: This document summarizes all silicon
errata issues from all revisions of silicon,
previous as well as current. Only the issues
indicated in the last column of Table 2
apply to the current silicon revision (A0).
Note: If you are unable to extract the silicon
revision level, please contact your local
Microchip sales office for assistance.
TABLE 1: SILICON DEVREV VALUES
Part Number Device ID
(1)
Revision ID for
Silicon
Revision
(2)
Part Number Device ID
(1)
Revision ID for
Silicon
Revision
(2)
A0 A1 A0 A1
PIC24F04KL100 4B01h
0000h 0001h
PIC24F08KL302 4B00h
0000h 0001h
PIC24F04KL101 4B02h PIC24F08KL401 4B0Eh
PIC24F08KL200 4B05h PIC24F08KL402 4B04h
PIC24F08KL201 4B06h PIC24F16KL401 4B1Eh
PIC24F08KL301 4B0Ah PIC24F16KL402 4B14h
Note 1: The Device IDs (DEVID and DEVREV) are located at the last two implemented addresses of configuration
memory space. They are shown in hexadecimal in the format “DEVID DEVREV”.
2: Refer to the “PIC24FXXKL1XX/2XX/3XX/4XX Flash Programming Specifications” (DS30625) for detailed
information on Device and Revision IDs for your specific device.
PIC24F16KL402 Family
Silicon Errata and Data Sheet Clarification
