2015-2018 Microchip Technology Inc. DS60001324C-page 1
PIC32MM0064GPL036 FAMILY
Operating Conditions
• 2.0V to 3.6V, -40°C to +125°C, DC to 25 MHz
• 2.0V to 3.6V, -40°C to +85°C, DC to 25 MHz
Low-Power Modes
• Low-Power modes:
- Idle: CPU off, peripherals run from system clock
- Sleep: CPU and peripherals off:
- Fast wake-up Sleep with retention
- Low-power Sleep with retention
•0.5 μA Sleep Current for Regulator Retention mode and
5 μA for Regulator Standby mode
• On-Chip 1.8V Voltage Regulator (VREG)
• On-Chip Ultra Low-Power Retention Regulator
High-Performance 32-Bit RISC CPU
• microAptiv™ UC 32-Bit Core with 5-Stage Pipeline
• microMIPS™ Instruction Set for 35% Smaller Code and
98% Performance compared to MIPS32 Instructions
• DC-25 MHz Operating Frequency
• 3.17 CoreMark
®
/MHz (79 CoreMark) Performance
• 1.53 DMIPS/MHz (37 DMIPS) (Dhrystone 2.1) Performance
• 16-Bit/32-Bit Wide Instructions with 32-Bit Wide Data Path
• Two Sets of 32 Core Register Files (32-bit) to Reduce
Interrupt Latency
• Single-Cycle 32x16 Multiply and Two-Cycle 32x32 Multiply
• Hardware Divide Unit
• 64-Bit, Zero Wait State Flash with ECC to Maximize
Endurance/Retention
Microcontroller Features
• Low Pin Count Packages, Ranging from 20 to 36 Pins,
including UQFN as Small as 4x4 mm
• Up to 64K Flash Memory:
- 20,000 erase/write cycle endurance
- 20 years minimum data retention
- Self-programmable under software control
• Up to 8K Data Memory
• Pin-Compatible with Most PIC24 MCU/dsPIC
®
DSC Devices
• Multiple Interrupt Vectors with Individually
Programmable Priority
• Fail-Safe Clock Monitor mode
• Configurable Watchdog Timer with On-Chip, Low-Power
RC Oscillator
• Programmable Code Protection
• Selectable Oscillator Options including:
- High-precision, 8 MHz internal Fast RC (FRC) oscillator
- High-speed crystal/resonator oscillator or external clock
- 2x/3x/4x/6x/12x/24x PLL, which can be clocked from the
FRC or primary oscillator
Peripheral Features
• Atomic Set, Clear and Invert Operation on Select
Peripheral Registers
• High-Current Sink/Source 11 mA/16 mA on All Ports
• Independent, Low-Power 32 kHz Timer Oscillator
• Two 4-Wire SPI modules (up to 25 MHz non-PPS,
20 MHz PPS):
- 16-byte FIFO
-I
2
S mode
• Two UARTs:
- RS-232, RS-485 and LIN/J2602 support
- IrDA
®
with on-chip hardware encoder and decoder
• External Edge and Level Change Interrupt on All Ports
• CRC module
• Hardware Real-Time Clock and Calendar (RTCC)
• Up to 20 Peripheral Pin Select (PPS) Remappable Pins
• Seven Total 16-Bit Timers:
- Timer1: Dedicated 16-bit timer/counter
- Two additional 16-bit timers in each MCCP and SCCP
module
• Capture/Compare/PWM/Timer modules:
- Two 16-bit timers or one 32-bit timer in each module
- PWM resolution down to 21 ns
- One Multiple Output (MCCP) module:
- Flexible configuration as PWM, input capture, output
compare or timers
- Six PWM outputs
- Programmable dead time
- Auto-shutdown
- Two Single Output (SCCP) modules:
- Flexible configuration as PWM, input capture, output
compare or timers
- Single PWM output
• Reference Clock Output (REFO)
• Two Configurable Logic Cells (CLC) with Internal
Connections to Select Peripherals and PPS
Debug Features
• Two Programming and Debugging Interfaces:
- 2-wire ICSP™ interface with non-intrusive access
and real-time data exchange with application
-4-wire MIPS
®
standard Enhanced JTAG interface
• IEEE Standard 1149.2 Compatible (JTAG) Boundary Scan
32-Bit Flash Microcontroller with MIPS32
®
microAptiv™ UC Core
with Low Power and Low Pin Count
