2011-2016 Microchip Technology Inc. DS80000531H-page 1
PIC32MX1XX/2XX 28/36/44-PIN
The PIC32MX1XX/2XX 28/36/44-pin family devices that
you have received conform functionally to the current
Device Data Sheet (DS60001168J), except for the
anomalies described in this document.
The errata described in this document will be addressed
in future revisions of the PIC32MX1XX/2XX 28/36/44-
pin silicon.
Data Sheet clarifications and corrections start on page
12, following the discussion of silicon issues.
The silicon revision level can be identified using the
current version of MPLAB
®
X IDE and Microchip’s
programmers, debuggers and emulation tools, which
are available at the Microchip corporate web site
(www.microchip.com).
For example, to identify the silicon revision level
using MPLAB X IDE in conjunction with a hardware
debugger:
1. Using the appropriate interface, connect the
device to the hardware debugger.
2. Open an MPLAB X IDE project.
3. Configure the MPLAB X IDE project for the
appropriate device and hardware debugger.
4. Select Window > Dashboard
, and then click
the Refresh Debug Tool Status icon
().
5. The part number and the Device and
Revision ID values appear in the Output
window.
The Device and Revision ID values for the various
silicon revisions are provided in Tabl e 1 through
Table 4.
Note: The silicon issues discussed in the
following pages are for silicon revisions
with the Device and Revision IDs listed in
Table 1 through Table 4. The last column
of each table represents the latest silicon
revision for the devices listed. The silicon
issues are summarized in Tab le 5 .
Note: If you are unable to extract the silicon
revision level, please contact your local
Microchip sales office for assistance.
TABLE 1: SILICON DEVREV VALUES FOR DEVICES WITH 16/32 KB FLASH
Part Number Device ID
(1)
Revision ID for Silicon Revision
(1)
A0 A1
PIC32MX110F016B 0x4A07053
0x0 0x1
PIC32MX110F016C 0x4A09053
PIC32MX110F016D 0x4A0B053
PIC32MX210F016B 0x4A01053
PIC32MX210F016C 0x4A03053
PIC32MX210F016D 0x4A05053
PIC32MX120F032B 0x4A06053
PIC32MX120F032C 0x4A08053
PIC32MX120F032D 0x4A0A053
PIC32MX220F032B 0x4A00053
PIC32MX220F032C 0x4A02053
PIC32MX220F032D 0x4A04053
Note 1: Refer to the “Memory Organization” and “Special Features” chapters in the current Device Data Sheet
(DS60001168J) for detailed information on Device and Revision IDs for your specific device.
PIC32MX1XX/2XX 28/36/44-pin Family
Silicon Errata and Data Sheet Clarification
