8XC196KD/8XC196KD20
COMMERCIAL CHMOS MICROCONTROLLER
87C196KD/32 Kbytes of On-Chip OTPROM
83C196KD/32 Kbytes of ROM
■
16 MHz and 20 MHz Available
■
1000 Byte Register RAM
■
Register-to-Register Architecture
■
28 Interrupt Sources/16 Vectors
■
Peripheral Transaction Server
■
1.4 μs16x16Multiply(20MHz)
■
2.4 μs 32/16 Divide (20 MHz)
■
Powerdown and Idle Modes
■
Five 8-Bit I/O Ports
■
16-Bit Watchdog Timer
■
Dynamically Configurable 8-Bit or
16-Bit Buswidth
■
Full Duplex Serial Port
■
High Speed I/O Subsystem
■
16-Bit Timer
■
16-Bit Up/Down Counter with Capture
■
3 Pulse-Width-Modulated Outputs
■
Four 16-Bit Software Timers
■
8- or 10-Bit A/D Converter with
Sample/Hold
■
HOLD/HLDA Bus Protocol
OTP One-Time Programmable Version
The 8XC196KD 16-bit microcontroller is a high performance member of the MCS
®
96 microcontroller family.
The 8XC196KD is an enhanced 80C196KC device with 1000 bytes RAM, 16 MHz operation and an optional
32 Kbytes of ROM/EPROM. Intel’s CHMOS III process provides a high performance processor along with low
power consumption.
The 8XC196KD has a maximum guaranteed frequency of 16 MHz. The 8XC196KD20 has a maximum guaran-
teed frequency of 20 MHz. Unless otherwise noted, all references to the 8XC196KD also refer to the
8XC196KD20.
Four high-speed capture inputs are provided to record times when events occur. Six high-speed outputs are
availabl
e for pulse or waveform generation. The high-speed output can also generate four software timers or
start an A/ D conversion. Events can be based on the timer or up/down counter.
With the commercial (standard) temperature option, operational characteristics are guaranteed over the temp-
erature range of the 0°C to +70°C. With the extended (express) temperature range option, operational charac-
teristics are guaranteed over the temperature range of -40°C to +85°C. Unless otherwise noted, the specifica-
tions are the same for both options.
See the packaging information for extended temperature designators.
Extended Temperature Available
■
■
COPYRIGHT © INTEL CORPORATION, 2004 July 2004 Order Number: 272145-005
