R5F100FAAFP#V0 其他数据使用手册 - Renesas Electronics（瑞萨电子）

制造商:

Renesas Electronics（瑞萨电子）

分类:

微控制器

封装:

LQFP-44

描述:

微控制器, RL78/G1x Series Microcontrollers, RL78, 16位, 32 MHz, 16 KB, 2 KB

Pictures:

3D模型

符号图

焊盘图

引脚图

产品图

页面导航:

引脚图在P12Hot

原理图在P30

封装尺寸在P172P173P174P175P176P177P178P179P180P181P182P183

型号编码规则在P3P4P5P6P7P8P9P10P11P204P205

封装信息在P3P4P5P6P7P8P9P10P11

技术参数、封装参数在P4P5P6P7P8P9P10P11P50P51P52P53

应用领域在P119P120P121P122P123P124P125P126P127P128P129P130

电气规格在P50P51P52P53P54P55P56P57P58P59P60P61

型号编号列表在P3P4P5P6P7P8P9P10P11P204P205

导航目录

引脚图在P12
原理图在P30
封装尺寸在P172 P173 P174 P175 P176 P177 P178 P179 P180 P181 P182 P183
型号编码规则在P3 P4 P5 P6 P7 P8 P9 P10 P11 P204 P205
封装信息在P3 P4 P5 P6 P7 P8 P9 P10 P11
技术参数、封装参数在P4 P5 P6 P7 P8 P9 P10 P11 P50 P51 P52 P53
应用领域在P119 P120 P121 P122 P123 P124 P125 P126 P127 P128 P129 P130
电气规格在P50 P51 P52 P53 P54 P55 P56 P57 P58 P59 P60 P61
型号编号列表在P3 P4 P5 P6 P7 P8 P9 P10 P11 P204 P205

R5F100FAAFP#V0数据手册

Page:

of 207 Go

PDF下载

若手册格式错乱，请下载阅览PDF原文件

Datasheet

RL78/G13

RENESAS MCU

True low-power platform (66 μA/MHz, and 0.57 μA for operation with only RTC and LVD) for the general-purpose

applications, with 1.6-V to 5.5-V operation, 16- to 512-Kbyte code flash memory, and 41 DMIPS at 32 MHz

R01DS0131EJ0350 Rev.3.50 1 of 200

Jun 30, 2020

R01DS0131EJ0350

Rev.3.50

Jun 30, 2020

1. OUTLINE

1.1 Features

Ultra-low power consumption technology

 V

DD = single power supply voltage of 1.6 to 5.5 V

 HALT mode

 STOP mode

 SNOOZE mode

RL78 CPU core

 CISC architecture with 3-stage pipeline

 Minimum instruction execution time: Can be changed

from high speed (0.03125 μs: @ 32 MHz operation

with high-speed on-chip oscillator) to ultra-low speed

(30.5 μs: @ 32.768 kHz operation with subsystem

clock)

 Address space: 1 MB

 General-purpose registers: (8-bit register × 8) × 4

banks

 On-chip RAM: 2 to 32 KB

Code flash memory

 Code flash memory: 16 to 512 KB

 Block size: 1 KB

 Prohibition of block erase and rewriting (security

function)

 On-chip debug function

 Self-programming (with boot swap function/flash shield

window function)

Data Flash Memory

 Data flash memory: 4 KB to 8 KB

 Back ground operation (BGO): Instructions can be

executed from the program memory while rewriting the

data flash memory.

 Number of rewrites: 1,000,000 times (TYP.)

 Voltage of rewrites: V

DD = 1.8 to 5.5 V

High-speed on-chip oscillator

 Select from 32 MHz, 24 MHz, 16 MHz, 12 MHz, 8 MHz,

6 MHz, 4 MHz, 3 MHz, 2 MHz, and 1 MHz

 High accuracy: +/- 1.0 % (V

DD = 1.8 to 5.5 V, TA = -20

to +85°C)

Operating ambient temperature

 T

A = -40 to +85°C (A: Consumer applications, D:

Industrial applications )

 T

A = -40 to +105°C (G: Industrial applications)

Power management and reset function

 On-chip power-on-reset (POR) circuit

 On-chip voltage detector (LVD) (Select interrupt and

reset from 14 levels)

DMA (Direct Memory Access) controller

 2/4 channels

 Number of clocks during transfer between 8/16-bit

SFR and internal RAM: 2 clocks

Multiplier and divider/multiply-accumulator

 16 bits × 16 bits = 32 bits (Unsigned or signed)

 32 bits ÷ 32 bits = 32 bits (Unsigned)

 16 bits × 16 bits + 32 bits = 32 bits (Unsigned or

signed)

Serial interface

 CSI: 2 to 8 channels

 UART/UART (LIN-bus supported): 2 to 4 channels

 I

C/Simplified I

C communication: 3 to 10 channels

Timer

 16-bit timer: 8 to 16 channels

 12-bit interval timer: 1 channel

 Real-time clock: 1 channel (calendar for 99 years,

alarm function, and clock

correction function)

 Watchdog timer: 1 channel (operable with the

dedicated low-speed on-chip

oscillator)

A/D converter

 8/10-bit resolution A/D converter (V

DD = 1.6 to 5.5 V)

 Analog input: 6 to 26 channels

 Internal reference voltage (1.45 V) and temperature

sensor

Note 1

I/O port

 I/O port: 16 to 120 (N-ch open drain I/O [withstand

voltage of 6 V]: 0 to 4, N-ch open drain I/O

DD withstand voltage

Note 2

/EVDD withstand

voltage

Note 3

]: 5 to 25)

 Can be set to N-ch open drain, TTL input buffer, and

on-chip pull-up resistor

 Different potential interface: Can connect to a 1.8/2.5/3

V device

 On-chip key interrupt function

 On-chip clock output/buzzer output controller

Others

 On-chip BCD (binary-coded decimal) correction circuit

Notes 1. Can be selected only in HS (high-speed main)

mode

2. Products with 20 to 52 pins

3. Products with 64 to 128 pins

Remark The functions mounted depend on the product.

See 1.6 Outline of Functions.
