Chip Resistor Surface Mount
w
ww.yageo.com
Apr 24, 2009 V.4
Product specification
2
9
SERIES
RC
0603 (RoHS Compliant)
Y
Y
A
A
G
G
E
E
O
O
B
B
R
R
A
A
N
N
D
D
o
o
r
r
d
d
e
e
r
r
i
i
n
n
g
g
c
c
o
o
d
d
e
e
GLOBAL PART NUMBER
(
PREFERRED
)
RC0603 X R - XX XXXX L
(
1
)
(
2
)
(
3
)
(
4
)
(
5
)
(
6
)
(
1
)
TOLERANCE
F = ±1%
J = ±5% (for Jumper ordering, use code of J)
(
2
)
PACKAGING TYPE
R = Paper / PE taping reel
(
3
)
TEMPERATURE COEFFICIENT OF RESISTANCE
– = Base on spec
(
4
)
TAPING REEL
07 = 7 inch dia. Reel
10 = 10 inch dia. Reel
13 = 13 inch dia. Reel
(
5
)
RESISTANCE VALUE
There are 2~4 digits indicated the resistor value. Letter R/K/M is decimal point, no need
to mention the last zero after R/K/M, e.g.1K2, not 1K20.
Detailed resistance rules show in table of “Resistance rule of global part number”.
(6) OPTIONAL CODE
L = optional symbol
(Note)
ORDERING INFORMATION
-
GLOBAL PART NUMBER & 12NC
Both part numbers are identified by the series, size, tolerance, packing
type, temperature coefficient, taping reel and resistance value.
SCOPE
This specification describes
RC0603 series chip resistors
with lead-free terminations made
by thick film process.
APPLICATIONS
All general purpose application
FEATURES
RoHS compliant
- Products with lead free
terminations meet RoHS
requirements
- Pb-glass contained in electrodes,
resistor element and glass are
exempted by RoHS
Reducing environmentally
hazardous wastes
High component and equipment
reliability
Saving of PCB space
None forbidden-materials used
in products/production
Halogen Free Epoxy
O
RDERING EXAMPLE
The ordering code of a RC0603
chip resistor, value 56 X with
±1% tolerance, supplied in 7-inch
tape reel is: RC0603FR-0756R(L).
NOTE
1. All our RSMD products meet RoHS
compliant. "LFP" of the internal 2D reel
label mentions "Lead Free Process"
2. On customized label, "LFP" or specific
symbol printed and the optional "L" at
the end of GLOBAL PART NUMBER /
12NC can be added (both are on
customer request)
Resistance rule of
global part
number
Resistance code rule
Example
0R 0R = Jumpe
r
XRXX
(1 to 9.76 Ω)
1R = 1 Ω
1R5 = 1.5 Ω
9R76 = 9.76 Ω
XXRX
(10 to 97.6 Ω)
10R = 10 Ω
97R6 = 97.6 Ω
XXXR
(100 to 976 Ω)
100R = 100 Ω
XKXX
(1 to 9.76 KΩ)
1K = 1,000 Ω
9K76 = 9760 Ω
XMXX
(1 to 9.76 MΩ)
1M = 1,000,000 Ω
9M76= 9,760,000 Ω
