Rev Date: 06/04/2018
1 www.seielect.com
This specification may be changed at any time without prior notice. marketing@seielect.com
Please confirm technical specifications before you order and/or use.
RoHS Compliance Status
Stackpole Electronics, Inc.
Resistive Product Solutions
Stackpole Electronics has joined the worldwide effort to reduce the amount of lead in electronic components and to
meet the various regulatory requirements now prevalent, such as the European Union’s directive regarding “Restrictions
on Hazardous Substances” (RoHS 3). As part of this ongoing program, we periodically update this document with the
status regarding the availability of our compliant components. All our standard part numbers are compliant to EU
Directive 2011/65/EU of the European Parliament as amended by Directive (EU) 2015/863/EU as regards the list of
restricted substances.
Note (1): RoHS Compliant by means of exemption 7c-I.
Resistors
ASR
Anti-Surge Leaded Resistor Axial YES 99.3/0.7 Sn/Cu Apr-05 05/14
ASRM
Mini-Anti Surge Leaded Resistor Axial YES 99.3/0.7 Sn/Cu Apr-05 05/14
BR
Open Air Bare Element
Current Sense Resistor
Special YES 100% Matte Sn Jan-06 06/01
BVM
Ceramic Housed Vertical Wirewound
Bracket Mount Resistor
Special YES 100% Matte Sn Always Always
CB
General Purpose Ceramic Housed with
Axial Leads Wirewound Resistor
Axial YES 100% Matte Sn Jan-06 06/01
CD
Axial Leaded Zero Ohm Resistor Axial YES 100% Matte Sn Jan-04 04/01
CF
Carbon Film Leaded Resistor Axial YES 100% Matte Sn Jan-04 (Taiwan, China) 04/01
CFM
Mini-Carbon Film Leaded Resistor Axial YES 100% Matte Sn Jan-04 (Taiwan, China) 04/01
CSM
Molded Metal Plate Sensing Resistor SMD YES 100% Matte Sn over Ni Always Always
CSNL
Metal Foil Current Sensing
Surface Mount Chip Resistor
SMD YES 100% Matte Sn over Ni May-04 04/18
CSR
Thick Film Current Sensing
Surface Mount Chip Resistor
SMD YES(1) 100% Matte Sn over Ni May-04 04/18
CSRF
Foil on Ceramic Current Sensing
Surface Mount Chip Resistor
SMD YES 100% Matte Sn over Ni Jul-04 04/27
CSRN
Thick Film Current Sensing
Surface Mount Chip Resistor, Narrow
SMD YES(1) 100% Matte Sn over Ni May-04 04/18
CSS
Ultra Precision Current Sensing
Chip Resistor
SMD YES 100% Matte Sn over Ni Always Always
CSSH
Ultra Precision Current Sensing
Chip Resistor (High Power)
SMD YES 100% Matte Sn over Ni Always Always
CSSK
Kelvin Termination Current Sensing
Resistor
SMD YES 100% Matte Sn over Ni Always Always
EL/CEL
Commercial Power Resistor (Uncoated)
DISCONTINUED(July 1, 2014)
Axial YES 100% Matte Sn Always Always
ESD(U)
Low and Ultra-Low Capacitance
ESD Suppressor
SMD YES 100% Matte Sn over Ni Always Always
EWT
Non-Flammable Edgewound
Tubular Wirewound Vitrewous
Enamel Coating Resistor
Special YES 100% Matte Sn Always Always
FCR
Trimmable Thick Film
Surface Mount Chip Resistor
SMD YES(1) 100% Matte Sn over Ni Jan-04 04/01
FRN
Axial Leaded Fusing Resistor Axial YES 99.3/0.7 Sn/Cu Apr-05 05/14
GP
Commercial Grade - Conformal Coated
Leaded Wirewound Resistor
DISCONTINUED (July 1, 2014)
Axial YES 100% Matte Sn Jan-06 06/01
HCC
High Current Chassis Mount Shunt Resistor SMD YES 100% Copper Always Always
HCJ
Molded Metal Plate Sensing Resistor SMD YES 100% Matte Sn over Ni Always Always
HCS
High Current Shunt Resistor SMD YES 100% Copper Always Always
HCSK
Kelvin Termination Current Shunt Resistor SMD YES 100% Copper Always Always
HDM
Moisture Resistant Carbon Film
Leaded Resistor
Axial YES 100% Matte Sn Always Always
HGC
Thick Film Precision High Resistance Chip
Resistor
SMD YES(1) 100% Matte Sn over Ni Always Always
Lead-Free
Effective Date
Code
(YY/WW)
Standard
Product
Series
Description
Package /
Termination
Type
Standard
Series RoHS
Compliant
Lead-Free Termination
Composition
Lead-Free
Mfg. Effective Date
(Std Product Series)
