RN73C2A10KBTDF 其他数据使用手册 - TE Connectivity（泰科）
制造商:
TE Connectivity（泰科）
分类:
贴片电阻
封装:
0805
描述:
TE CONNECTIVITY RN73C2A10KBTDF 片式电阻器, 表面贴装, 薄膜, RN73系列, 10 kohm, 100 V, 0805 [2012公制], 100 mW, ± 0.1%
Pictures:
3D模型
符号图
焊盘图
引脚图
产品图
页面导航:
标记信息在P1
导航目录
RN73C2A10KBTDF数据手册
Page:
of 2 Go
若手册格式错乱，请下载阅览PDF原文件
Form Type Distribute Version 2.0 Ref IPC 1752A Sectionals Material Info Subsectionals D, A
Supplier Information
Company Name TE Connectivity Request
Document ID
Contact Name John R. Penica Contact Title Mgr. Global Product Compliance
Company
Unique ID
TE Connectivity Response Date 2016-06-15 Contact Email jrpenica@te.com
Contact Phone Number 717-592-3266
Legal Statement
Supplier
Acceptance
true
Legal Statement
The information provided in this document is based upon reasonable inquiry of our suppliers. This information is subject to change. This information does not in any
way modify existing purchase specifications or existing contractual or other agreements terms between TE Connectivity (or its affiliated companies) and its customers.
Product
Manufacturer
Item number
1676153-2 Amount 4.70724 Version - Identity
Manufacturer
Item Name
RN 0805 10K
0.1% 10PPM
1KRL
Weight Uom mg Mfr Site Authority
Date UOM Each
EURoHS-0508 Product(s) meets EU RoHS requirement without any exemptions
ChinaRoHS-
0508
Product(s) is eligible for marking with the e code under China's Measures for Administration of the control of pollution by Electronic Information
Products
EUREACH-0615 REACH Candidate Substances of Very High Concern ARE NOT Contained in the Product Above the Limits per the Definition within REACH
Product Disclosure
Sub-
Item/Material/
Substance
Level Name Substance
Category
Substance
CAS
Substance
Concentration
Quantity Mass per Unit UOM Exemption
Material 1 Nickel Plating 1.0 0.01270013 mg
Substance 2 Nickel Nickel 7440-02-0 100.0 1.0 0.01270013 mg
Material 1 Resistor Layer 1.0 1.882896E-5 mg
Substance 2 Contains No
Reportable
TE5081-2
Substances
Supplier TE5081-2-
1212
100.0 1.0 1.882896E-5 mg
Material 1 Backside
Electrode
1.0 0.05379905 mg
Substance 2 Ethanol, 2-(2-
butoxyethoxy)-
Supplier 112-34-5 20.0 1.0 0.01075981 mg
Substance 2 Copper oxide
(CuO)
Supplier 1317-38-0 10.0 1.0 0.0053799 mg
Substance 2 Terpineol Supplier 8000-41-7 15.0 1.0 0.00806986 mg
Substance 2 Silver Supplier 7440-22-4 55.0 1.0 0.02958948 mg
Material 1 Marking 1.0 0.02379981 mg
Substance 2 Titanium oxide
(TiO2)
Supplier 13463-67-7 20.0 1.0 0.00475996 mg
Substance 2 Cellulose, ethyl
ether
Supplier 9004-57-3 80.0 1.0 0.01903984 mg
Material 1 Tin Plating 1.0 0.02980154 mg
Substance 2 Tin Supplier 7440-31-5 100.0 1.0 0.02980154 mg
Material 1 Overcoat 1.0 0.0433019 mg
Substance 2 Ethanol, 2-(2-
butoxyethoxy)-
Supplier 112-34-5 12.0 1.0 0.00519623 mg
Substance 2 Carbon black Supplier 1333-86-4 3.0 1.0 0.00129906 mg
Substance 2 Resin acids
and Rosin
acids
Supplier 73138-82-6 35.0 1.0 0.01515567 mg
Substance 2 Acetamide Supplier 60-35-5 20.0 1.0 0.00866038 mg
Substance 2 Talc
(Mg3H2(SiO3)
4)
Supplier 14807-96-6 10.0 1.0 0.00433019 mg
Substance 2 Silica, vitreous Supplier 60676-86-0 20.0 1.0 0.00866038 mg
Material 1 Upside
Electrode
1.0 0.05379905 mg
Substance 2 Ethanol, 2-(2-
butoxyethoxy)-
Supplier 112-34-5 20.0 1.0 0.01075981 mg
Substance 2 Copper oxide
(CuO)
Supplier 1317-38-0 10.0 1.0 0.0053799 mg
Substance 2 Terpineol Supplier 8000-41-7 15.0 1.0 0.00806986 mg
Substance 2 Silver Supplier 7440-22-4 55.0 1.0 0.02958948 mg
Material 1 Substrate 1.0 4.48999617 mg
