RT8020
1
DS8020-05 March 2011 www.richtek.com
Applications
Mobile Phones
Personal Information Appliances
Wireless and DSL Modems
MP3 Players
Portable Instruments
Note :
Richtek products are :
` RoHS compliant and compatible with the current require-
ments of IPC/JEDEC J-STD-020.
` Suitable for use in SnPb or Pb-free soldering processes.
Ordering Information
Pin Configurations
(TOP VIEW)
WDFN-12L 3x3
Dual High-Efficiency PWM Step-Down DC/DC Converter
Features
2.5V to 5.5V Input Range
Adjustable Output From 0.6V to V
IN
1.2V, 1.3V, 1.8V, 2.5V and 3.3V Fixed/ Adjustable
Output Voltage
1A Output Current
95% Efficiency
No Schottky Diode Required
50uA Quiescent Current per Channel
1.5MHz Fixed Frequency PWM Operation
Small 12-Lead WDFN Package
RoHS Compliant and 100% Lead (Pb)-Free
Marking Information
For marking information, contact our sales representative
directly or through a Richtek distributor located in your
area, otherwise visit our website for detail.
General Description
The RT8020 is a dual high-efficiency Pulse-Width-
Modulated (PWM) step-down DC/DC converter. It is
capable of delivering 1A output current over a wide input
voltage range from 2.5V to 5.5V, the RT8020 is ideally
suited for portable electronic devices that are powered
from 1-cell Li-ion battery or from other power sources within
the range such as cellular phones, PDAs and other hand-
held devices.
Two operational modes are available : PWM/Low-Dropout
auto-switch and shutdown modes. Internal synchronous
rectifier with low R
DS(ON)
dramatically reduces conduction
loss at PWM mode. No external Schottky diode is
required in practical application.
The RT8020 enters Low-Dropout mode when normal PWM
cannot provide regulated output voltage by continuously
turning on the upper PMOS. The RT8020 enter shutdown
mode and consumes less than 0.1μA when EN pin is pulled
low.
The switching ripple is easily smoothed-out by small
package filtering elements due to a fixed operation
frequency of 1.5MHz. This along with small
WDFN-12L 3x3 package provides small PCB area
application. Other features include soft start, lower internal
reference voltage with 2% accuracy, over temperature
protection, and over current protection.
VIN2
LX2
NC1
FB1
EN2
NC2
FB2
LX1
GND
GND
EN1
VIN1
11
10
9
1
2
3
4
5
12
67
8
GND
13
RT8020
Package Type
QW : WDFN-12L 3x3 (W-Type)
Lead Plating System
P : Pb Free
G : Green (Halogen Free and Pb Free)
Output Voltage : VOUT1/VOUT2
Default : Adjustable
A : 3.3V/1.8V
B : 3.3V/1.3V
C : 3.3V/1.2V
D : 2.5V/1.8V
