US
UK
Taiwan
China
Singapore
+1-847-639-6400 sales@coilcraft.com
+44-1236-730595 sales@coilcraft-europe.com
+886-2-2264 3646 sales@coilcraft.com.tw
+86-21-6218 8074 sales@coilcraft.com.cn
+ 65-6484 8412 sales@coilcraft.com.sg
© Coilcraft Inc. 2012
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check out web site for latest information.
0.755 ±0.02
19,18 ±0,51
0.736 ±0.034
18,70 ±0,86
Recommended Land Pattern
0.185
4,70
0.210
5,33
0.365 ±0.02
9,27 ±0,51
Internal code
0.160
4,06
0.470
11,94
12
3
Height
(See table)
typ
0.004/0,102
0.290
7,37
0.015
0,38
0.150
3,81
0.100 ±0.003
2,54 ±0,076
0.100
2,54
0.125
3,18
0.311 ±0.015
7,90 ±0,38
0.515±0.015
13,08 ±0,37
0.130
3,30
*
0.150
3,81
0.260
6,60
C
L
C
L
*
Width of flat area on winding
Dimensions are in
inches
mm
SER20xx-xxxL
XXXX Y
0.412 ±0.034
10,46 ±0,86
Maximum
height Weight
SER2009 0.34 / 8,64 6.65 – 6.89 g
SER2010 0.37
SER2011 0.42
SER2012 0.47
SER2013 0.51
SER2014 0.55
/ 9,40 7.46 – 7.90 g
/ 10,67 8.63 – 9.08 g
/ 11,94 9.92 – 10.3 g
/ 12,95 10.8 – 11.4 g
/ 13,97 11.7 – 12.4 g
Document 349-1 Revised 09/05/12
Shielded Power Inductor
–
SER2000
Document 349-1
1
2
3
Caution:
Terminal 3 is provided for mounting
stability only. This terminal is connected
to the winding of the inductor and must
not be connected to ground or any
circuitry.
Packaging
SER2009 200 per 13″ reel; Plastic tape: 44 mm wide, 0.4 mm thick, 32 mm pocket spacing, 9.25 pocket depth
SER2010 200 per 13″ reel; Plastic tape: 44 mm wide, 0.4 mm thick, 32 mm pocket spacing, 10.5 pocket depth
SER2011 170 per 13″ reel; Plastic tape: 44 mm wide, 0.4 mm thick, 32 mm pocket spacing, 11.6 pocket depth
SER2012 150 per 13″ reel; Plastic tape: 44 mm wide, 0.4 mm thick, 32 mm pocket spacing, 13.0 pocket depth
SER2013 150 per 13″ reel; Plastic tape: 44 mm wide, 0.5 mm thick, 32 mm pocket spacing, 14.0 pocket depth
SER2014 125 per 13″ reel; Plastic tape: 44 mm wide, 0.5 mm thick, 32 mm pocket spacing, 15.0 pocket depth
Designer’s Kit C374 contains 2 each of nine parts.
Core material Ferrite
Core and winding loss See www.coilcraft.com/coreloss
Terminations RoHS compliant tin-silver over copper. Other
terminations available at additional cost.
Ambient temperature –40°C to +85°C with Irms current, +85°C to
+125°C with derated current
Storage temperature Component: –40°C to +125°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL) 1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
PCB washing Only pure water or alcohol recommended
• Designedforhighcurrentpowersupplyapplications
•FlatwirewindingsprovideexceptionallylowDCR
• Isat ratings as high as 100 A
