RT9164A
4
DS9164A-15 April 2011
www.richtek.com
Absolute Maximum Ratings (Note 1)
Supply Input Voltage -------------------------------------------------------------------------------------------------------- 15V
Power Dissipation, P
D
@ T
A
= 25°C
SOT-223 ----------------------------------------------------------------------------------------------------------------------- 0.740W
TO-252 ------------------------------------------------------------------------------------------------------------------------- 1.471W
TO-263 ------------------------------------------------------------------------------------------------------------------------- 2.222W
Package Thermal Resistance (Note 2)
SOT-223, θ
JA
------------------------------------------------------------------------------------------------------------------ 135°C/W
SOT-223, θ
JC
----------------------------------------------------------------------------------------------------------------- 19°C/W
TO-252, θ
JA
------------------------------------------------------------------------------------------------------------------- 68°C/W
TO-252, θ
JC
------------------------------------------------------------------------------------------------------------------- 7.5°C/W
TO-263, θ
JA
------------------------------------------------------------------------------------------------------------------- 45°C/W
TO-263, θ
JC
------------------------------------------------------------------------------------------------------------------- 7.8°C/W
Lead Temperature (Soldering, 10 sec.) --------------------------------------------------------------------------------- 260°C
Junction Temperature ------------------------------------------------------------------------------------------------------- 150°C
Storage Temperature Range ---------------------------------------------------------------------------------------------- −65°C to 150°C
ESD Susceptibility (Note 3)
HBM (Human Body Mode) ------------------------------------------------------------------------------------------------ 8kV
MM (Machine Mode) -------------------------------------------------------------------------------------------------------- 750V
Electrical Characteristics
(T
A
= 25°C, unless otherwise specified)
Recommended Operating Conditions (Note 4)
Supply Input Voltage -------------------------------------------------------------------------------------------------------- 3V to 14V
Junction Temperature Range ---------------------------------------------------------------------------------------------- −40°C to 125°C
To be continued
Parameter Symbol Test Conditions Min Typ Max Unit
I
OUT
= 10mA, (V
IN
V
OUT
) = 2V,
T
A
= 25C
1.243 1.256 1.281 V
Reference Voltage
(Note 5)
RT9164A V
REF
10mA I
OUT
1.0A,
1.5V V
IN
V
OUT
10V
1.231 1.256 1.294 V
I
OUT
= 10mA, V
IN
= 3.3V, T
J
= 25C 1.485 1.5 1.53
RT9164A -15
10mA I
OUT
1.0A, 3.3V V
IN
10V 1.470 1.5 1.55
I
OUT
= 10mA, V
IN
= 3.3V, T
J
= 25C 1.797 1.815 1.85
RT9164A -18
10mA I
OUT
1.0A, 3.3V V
IN
10V 1.779 1.815 1.87
I
OUT
= 10mA, V
IN
= 4.0V, T
J
= 25C 2.475 2.500 2.550
RT9164A -25
10mA I
OUT
1.0A, 4.0V V
IN
10V 2.450 2.500 2.575
I
OUT
= 10mA, V
IN
= 4.25V, T
J
= 25C 2.822 2.850 2.910
RT9164A -28
10mA I
OUT
1.0A, 4.25V V
IN
10V 2.793 2.850 2.936
I
OUT
= 10mA, V
IN
= 4.5V, T
J
= 25C 2.970 3.000 3.060
Output Voltage
(Note 5)
RT9164A -30
V
OUT
10mA I
OUT
1.0A, 4.5V V
IN
10V 2.940 3.000 3.090
V
