SCC SMT Series
Microstructure
Pressure Sensors
0 psi to 5 psi through
0 psi to 100 psi
The SCC SMT Series offers an extremely low-cost sensor
element with a temperature-stable output when driven with a
constant current source. These integrated circuit sensors were
designed for extremely cost-sensitive applications where
precise accuracy over a wide temperature range is not
required.
The standard surface mount package includes an optional
ported lid to fit in a variety of applications.
The absolute devices have an internal vacuum reference and
an output voltage proportional to absolute pressure. The
differential devices allow application of pressure to either side
of the sensing diaphragm and can be used for gage or
differential measurements.
The 4-pin closed bridge configuration allows electrical
connection with additional pads provided for mechanical
support. Pulsed power is recommended to achieve maximum
accuracy and conserve battery power in portable applications.
FEATURES
• Low cost
• Small size
• Internal temperature compensation
• Absolute or gage pressures
• High-impedance bridge
• Low power consumption
POTENTIAL APPLICATIONS
• Pneumatic controls
• Automotive diagnostics
• Medical equipment/instrumentation
• Dental equipment
• Environmental controls
• Barometric pressure measurement
• Altimeters
• Pneumatic controls
• Battery powered equipment
