Datasheet -- SDX30D4
Representative photograph,
actual product appearance
may vary.
Due to regional agency
approval requirements,
some products may not be
available in your area.
Please contact your
regional Honeywell office
regarding your product of
choice.
SDX30D4
Pressure Sensors: Measurement Type: Differential, Gage; 0
psid to 30 psid, Temperature Compensated Sensor, "D4"
DIP Package - Straight Port
Features
● Low Cost DIP
● Precision Temperature Compensation
● Calibrated Zero & Span
● Small Size
● Low Noise
● High Impedance for Low Power Applications
● Prime Grade Available (SDXxxxyy-A)
Typical Applications
● Medical Equipment
● Computer Peripherals
● Pneumatic Controls
● HVAC
Description
The SDX series sensors provide a very cost effective solution for
pressure applications that require small size plus performance.
These calibrated and temperature compensated sensors give an
accurate and stable output over a 0 °C to 50 °C [32 °F to 122 °F]
temperature range. This series is intended for use with non-
corrosive, non-ionic working fluids such as air, dry gases and the
like.
Devices are available to measure absolute and gage pressures from
1 psi (SDX01) up to 100 psi (SDX100). The absolute devices have
an internal vacuum reference and an output voltage proportional to
absolute pressure.
SDX Sensors are available in standard commercial and prime grades
