EFM8 Busy Bee Family
EFM8BB3 Data Sheet
The EFM8BB3, part of the Busy Bee family of MCUs, is a per-
formance line of 8-bit microcontrollers with a comprehensive ana-
log and digital feature set in small packages.
These devices offer state-of-the-art performance by integrating 12-bit ADC, internal
temperature sensor, and up to two 12-bit DACs into small packages, making them ideal
for general purpose applications. With an efficient, pipelined 8051 core with maximum
operating frequency at 50 MHz, various communication interfaces, and four channels
of configurable logic, the EFM8BB3 family is optimal for many embedded applications.
EFM8BB3 applications include the following:
KEY FEATURES
• Pipelined 8-bit 8051 MCU Core with
50 MHz operating frequency
• Up to 29 multifunction I/O pins
• One 12-bit/10-bit ADC
• Four 12-bit DACs with synchronization and
PWM capabilities
• Two low-current analog comparators with
built-in reference DACs
• Internal temperature sensor
• Internal 49 MHz and 24.5 MHz oscillators
accurate to ±2%
• Four channels of Configurable Logic
• 6-channel PWM / PCA
• Six 16-bit general-purpose timers
• Consumer electronics
• Precision instrumentation
• Power management and control
• Industrial control and automation
• Smart sensors
I/O Ports
Core / Memory Clock Management
CIP-51 8051 Core
(50 MHz)
High Frequency
49 MHz RC
Oscillator
Energy Management
Brown-Out Detector
8-bit SFR bus
Serial Interfaces Timers and Triggers Analog Interfaces
SPI
Security
Pin Reset
ADC
2 x
Comparators
Internal
Voltage
Reference
16-bit CRC
Flash Program
Memory
(up to 64 KB)
RAM Memory
(up to 4352 bytes)
Debug Interface
with C2
Lowest power mode with peripheral operational:
IdleNormal ShutdownSuspend Snooze
Timer 3/4
Up to 4 x
Voltage DAC
High Frequency
24.5 MHz RC
Oscillator
Pin Wakeup
External
Interrupts
General
Purpose I/O
I
2
C / SMBus
2 x UART
High-Speed
I2C Slave
External
Oscillator
Low Frequency
RC Oscillator
4 x Configurable Logic Units
Watchdog
Timer
PCA/PWM
Timers
0/1/2/5
Internal LDO
Regulator
Power-On Reset
silabs.com | Smart. Connected. Energy-friendly. Preliminary Rev. 0.2
This information applies to a product under development. Its characteristics and specifications are subject to change without notice.
