Product Group: Diodes Division / August 29, 2016 / PCN-DD-014-2016 Rev. 0
6 inch Wafer Conversion for All Automotive Grade PAR
®
TVS Products
and Strip plating Conversion for TPSMB and TPC Product Series
DESCRIPTION OF CHANGE: Vishay Diodes Division will change wafer diameter from 4 inch to 6
inch for all automotive grade PAR® TVS. In addition to wafer diameter
change, the TPSMB and TPC product series plating method for lead
finishing will be changed from barrel to strip plating to improve plating
thickness uniformity
(Note1)
.
Also, cathode band will be added on devices marking for TPCxxA
series. The following marking example provides the details of the
change:
Qualification test has been confirmed to meet and pass all specifications for automotive grade.
There will be no change in form, fit or function of final products.
Note 1: PCN for strip plating conversion of other automotive grade SMB and SMPC packaged products has
been issued in PCN-DD-005-2015.
CLASSIFICATION OF CHANGE: Wafer diameter / Plating method change / Marking change
REASON FOR CHANGE: Capacity expansion / Product identification improvement
EXPECTED INFLUENCE ON QUALITY/RELIABILITY/PERFORMANCE:
No changes in quality and reliability performance
PRODUCT CATEGORY: PAR
®
TVS
PART NUMBERS/SERIES/FAMILIES AFFECTED:
Involved product groups are listed below and separated in 3 portions per involved changes:
1) Only wafer diameter change:
Existing P/N New Rev. P/N Existing P/N New Rev. P/N Existing P/N New Rev. P/N
3KASMC10AHE3_A/H 3KASMC10AHE3_B/H 3KASMC12AHE3_A/H 3KASMC12AHE3_B/H 3KASMC14AHE3_A/H 3KASMC14AHE3_B/H
3KASMC10AHE3_A/I 3KASMC10AHE3_B/I 3KASMC12AHE3_A/I 3KASMC12AHE3_B/I 3KASMC14AHE3_A/I 3KASMC14AHE3_B/I
3KASMC10AHM3_A/H 3KASMC10AHM3_B/H 3KASMC12AHM3_A/H 3KASMC12AHM3_B/H 3KASMC14AHM3_A/H 3KASMC14AHM3_B/H
3KASMC10AHM3_A/I 3KASMC10AHM3_B/I 3KASMC12AHM3_A/I 3KASMC12AHM3_B/I 3KASMC14AHM3_A/I 3KASMC14AHM3_B/I
3KASMC10HE3_A/H 3KASMC10AHE3_B/H 3KASMC12HE3_A/H 3KASMC12AHE3_B/H 3KASMC14HE3_A/H 3KASMC14AHE3_B/H
3KASMC10HE3_A/I 3KASMC10AHE3_B/I 3KASMC12HE3_A/I 3KASMC12AHE3_B/I 3KASMC14HE3_A/I 3KASMC14AHE3_B/I
3KASMC11AHE3_A/H 3KASMC11AHE3_B/H 3KASMC13AHE3_A/H 3KASMC13AHE3_B/H 3KASMC15AHE3_A/H 3KASMC15AHE3_B/H
3KASMC11AHE3_A/I 3KASMC11AHE3_B/I 3KASMC13AHE3_A/I 3KASMC13AHE3_B/I 3KASMC15AHE3_A/I 3KASMC15AHE3_B/I
3KASMC11AHM3_A/H 3KASMC11AHM3_B/H 3KASMC13AHM3_A/H 3KASMC13AHM3_B/H 3KASMC15AHM3_A/H 3KASMC15AHM3_B/H
3KASMC11AHM3_A/I 3KASMC11AHM3_B/I 3KASMC13AHM3_A/I 3KASMC13AHM3_B/I 3KASMC15AHM3_A/I 3KASMC15AHM3_B/I
3KASMC11HE3_A/H 3KASMC11AHE3_B/H 3KASMC13HE3_A/H 3KASMC13AHE3_B/H 3KASMC15HE3_A/H 3KASMC15AHE3_B/H
3KASMC11HE3_A/I 3KASMC11AHE3_B/I 3KASMC13HE3_A/I 3KASMC13AHE3_B/I 3KASMC15HE3_A/I 3KASMC15AHE3_B/I
